3M Products & Supplies

3M™ UHMW Film Tape 5421, Transparent, 1 in x 18 yd, 6.7 mil, 9 Roll/Case - 7000050075

Sold As: 9-Pack
SKU: 7000050075
MPN: 7000050075
For an accurate lead time please contact us
UPC: 00021200080081
3M ID: 70016040316
5 Digit UPC: 8008
$845.62 ($93.96 / Count)
Hurry up! Current stock:

Product Description

Used to protect surfaces from abrasion, 3M™ UHMW-PE Film Tape 5421 is a thin caliper general purpose polyethylene tape that creates a "slip plane" effect to allow contact without wear. This tape features a unique combination of properties that make it ideal for many tough impact wear or sliding applications. 3M™ UHMW-PE Film Tape 5421 is a thinner version of 3M™ UHMW-PE Film Tape 5423.

Features

  • Used in applications where lubrication is not possible because of contamination
  • Can help reduce squeaks, rattles and other noises that occur with movement
  • Rubber adhesive provides good initial tack for immediate bonding to material surface
  • Liner makes it ideal for fabricating or die-cutting into various lengths and shapes
  • Low coefficient of friction for “slip plane” effect between surfaces
  • Translucent, abrasion resistant backing helps protect surfaces from wear
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Tensile Strength (Imperial) UOMlb/in
Overall Width (Imperial)1.0
Overall Length (Imperial)18.0
Product ColorTransparent
Total Tape Thickness without Liner (Imperial)6.7
Maximum Operating Temperature (Fahrenheit) UOMDegree
Adhesion Strength (Metric)28.0
Tensile Strength (Metric) UOMN/100mm
Total Tape Thickness without Liner (Imperial) UOMmil
Minimum Operating Temperature (Celsius)-34.0
Overall Length (Imperial) UOMyd
Tensile Strength (Metric)796.0
Overall Width (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Specifications MetASTM D3330, ASTM D3652, ASTM D3759
Backing (Carrier) Thickness (Metric)0.13
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit)225.0
Minimum Operating Temperature (Fahrenheit)-30.0
Backing (Carrier) Thickness (Imperial) UOMmil
Backing (Carrier) Thickness (Metric) UOMmm
Tensile Strength (Imperial)30.0
Overall Length (Metric)16.5
Primary Liner60# Densified Kraft, Silicone Treated Paper
Backing (Carrier) Thickness (Imperial)5.0
Backing (Carrier) MaterialPolyethylene
Adhesive TypeRubber
Elongation at Break440%
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius) UOMDegree
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Metric)25.4
ApplicationGeneral Industrial
Adhesion Strength (Metric) UOMN/100mm
Overall Length (Metric) UOMm
Units per Case9.0
Maximum Operating Temperature (Celsius)107.0
Total Tape Thickness without Liner (Metric)0.17
Adhesion Strength26.0
IndustriesAerospace, Appliance, Automotive, Electronics, General Industrial, Metalworking, Military and Government, Specialty Vehicles, Transportation
