3M Products & Supplies

3M™ UHMW Film Tape 5423, Transparent, 2 in x 18 yd, 12 mil, 6 Roll/Case - 7000035835

Sold As: 6-Pack
SKU: 7000035835
MPN: 7000035835
For an accurate lead time please contact us
UPC: 00021200075766
3M ID: 70016040340
5 Digit UPC: 7576
$1,420.61 ($236.77 / Count)
Hurry up! Current stock:

Product Description

3M™ UHMW-PE Film Tape 5423 is a thick, general-purpose polyethylene tape made for high-impact, abrasion, and sliding applications. Its UPMW-PE (ultra-high molecular weight polyethylene) thermoplastic backing enables its low-friction and resistance to chemicals, abrasion, and vibration in demanding situations. The exceptional hardness and slick surface is ideal for maintaining a gliding, 'slip-plane' effect and reducing noises like squeaks and rattles. Furthering its workability, 3M™ UHMW-PE Film Tape 5423 is mounted on a liner, allowing the user to die-cut shapes to exact specifications. Between its low-friction coefficient, built-in liner, and long-lasting protection, this slick-surfaced tape excels in the aerospace, automotive, printing, and MRO industries.

Features

  • MAKE DIFFICULT SURFACES SLIPPERY: Great in applications where lubrication is not possible because of contamination
  • POWERFUL ADHESIVE: Rubber adhesive creates instant adhesion on countless surfaces
  • INSTANTLY PROTECT SURFACES: Translucent, abrasion resistant backing protects surfaces from wear
  • VERY LOW-FRICTION: Low coefficient of friction creates a 'slip plane' effect between surfaces
  • REDUCE UNWANTED NOISE: Can help reduce buzz, squeaks, rattles, and other noises that occur with movement
  • BUILT-IN LINER: The peel-off liner makes it ideal for fabricating or die-cutting into various part-specific lengths, shapes, and sizes
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Backing (Carrier) MaterialPolyethylene
Adhesive TypeRubber
Maximum Operating Temperature (Celsius) UOMDegree
Primary Liner60# Densified Kraft, Silicone Treated Paper
Overall Length (Imperial) UOMyd
Overall Width (Imperial)2.0
Backing (Carrier) Thickness (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit)225.0
Overall Width (Metric)51.0
Backing (Carrier) Thickness (Metric) UOMmm
Overall Length (Metric)16.5
Elongation at Break520%
Tensile Strength (Metric) UOMN/cm
Total Tape Thickness without Liner (Metric)0.3
Maximum Operating Temperature (Celsius)107.0
Tensile Strength (Metric)150.0
Overall Width (Imperial) UOMin
Minimum Operating Temperature (Fahrenheit)-30.0
Backing (Carrier) Thickness (Imperial)10.0
Product ColorTransparent
Adhesion Strength (Metric) UOMN/100mm
IndustriesAerospace, Appliance, Automotive, Electronics, General Industrial, MRO, Metalworking, Military and Government, Specialty Vehicles, Transportation
Units per Case6.0
Total Tape Thickness without Liner (Imperial)12.0
Adhesion Strength (Metric)28.0
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Maximum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius) UOMDegree
ApplicationReducing Wear Mechanical Equipment
Backing (Carrier) Thickness (Metric)0.25
Adhesion Strength26.0
Minimum Operating Temperature (Celsius)-34.0
Overall Length (Metric) UOMm
Overall Length (Imperial)18.0
Total Tape Thickness without Liner (Imperial) UOMmil
