3M Products & Supplies

3M™ UHMW Film Tape 5425, Transparent, 3/4 in x 18 yd, 5.1 mil, 16 Roll/Case - 7010373689

Sold As: 32-Pack
SKU: 7010373689
MPN: 7010373689
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138963248
3M ID: 70006396850
5 Digit UPC: 96324
$2,957.56 ($92.42 / Count)
Hurry up! Current stock:

Product Description

Used to protect surfaces from abrasion, 3M™ UHMW-PE Film Tape 5425 is a thin caliper general purpose polyethylene tape that creates a "slip plane" effect to allow contact without wear. This tape features outstanding chemical resistance and a unique combination of properties that make it ideal for many tough impact wear or sliding applications.

Features

  • Translucent, abrasion resistant backing helps protect surfaces from wear
  • Liner makes it ideal for fabricating or die-cutting into various lengths and shapes
  • Used in applications where lubrication is not possible because of contamination
  • Solvent and oil resistant adhesive provides high adhesion and chemical resistance in the most demanding applications
  • Low coefficient of friction for “slip plane” effect between surfaces
  • Can help reduce squeaks, rattles and other noises that occur with movement
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Overall Width (Imperial) UOMin
Backing (Carrier) Thickness (Metric)0.08
Overall Length (Metric) UOMm
Minimum Operating Temperature (Celsius)-34.0
Tensile Strength (Metric) UOMN/100mm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Imperial)0.75
Product ColorTransparent
Tensile Strength (Imperial) UOMlb/in
Total Tape Thickness without Liner (Metric) UOMmm
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Celsius)107.0
Overall Length (Metric)16.45
Specifications MetASTM D3330, ASTM D3652, ASTM D3759
Units per Case18.0
Backing (Carrier) Thickness (Imperial)3.0
Maximum Operating Temperature (Fahrenheit)225.0
Total Tape Thickness without Liner (Metric)0.13
Adhesion Strength30.0
Overall Width (Metric)19.05
Adhesion Strength (Metric) UOMN/100mm
Overall Length (Imperial) UOMyd
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Imperial)5.1
IndustriesAerospace, Appliance, Automotive, Electronics, General Industrial, Metalworking, Military and Government, Specialty Vehicles, Transportation
Adhesion Strength (Metric)33.0
Overall Length (Imperial)18.0
ApplicationVibration Damping
Tensile Strength (Metric)44.4
Minimum Operating Temperature (Fahrenheit) UOMDegree
Backing (Carrier) Thickness (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit)-30.0
Backing (Carrier) Thickness (Metric) UOMmm
Maximum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) MaterialPolyethylene
Units per Case UOMRoll
Total Tape Thickness without Liner (Imperial) UOMmil
Elongation at Break345%
Adhesive TypeAcrylic
Tensile Strength (Imperial)45.0
