3M Products & Supplies

3M™ Double Coated Tape GPT-020, Paper Liner, 1540mm x 50m, 1 Roll/Case - 7100369857

SKU: 7100369857
MPN: 7100369857
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00068060760524
3M ID: UU013569890
$987.99 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape GPT-020 is an 8 mil (200 micron), versatile, double-coated, pressure-sensitive adhesive tape made with a clear polyester carrier and white PCK liner with a red 3M™ logo. Because of the conformability of the film, it bonds to a variety of high to low-surface energy materials, such as stainless steel, acrylic, polycarbonate, aluminum, and more. Thanks to the formulation, this high tack tape allows for high-temperature applications up to 300 °F (149 °C) in short-term operations and up to 200 °F (93 °C) for long-term use. 3M™ Double Coated Tape GPT-020 can be used for a wide range of indoor and outdoor applications in various industries, such as automotive, electronics, transportation, manufacturing, and many more. For your convenience, the product is offered in standard roll format with a size range of 9 mm to 1540 mm widths and 50 m long. Additionally, you can choose the 1540 mm width and 500 m long roll. Trust 3M™ Double Coated Tape GPT-020 for your next project.

Features

  • HIGH INITIAL TACK: Made with a strong adhesive that sticks to high and low surface energy materials
  • PRODUCT OPTIONS: Available in standard roll format with a size range of 9 mm to 1540 mm widths and 50 m long, as well as a 1540 mm width and 500 m long roll
  • FLEXIBLE AND STRONG: An 8 mil (200 micron) thick double-coated tape with a white, 3.9 mil (100 micron) polycoated kraft (PCK - 58#) liner.
  • MULTIPURPOSE: Works across many applications, including point-of-purchase displays, indoor and outdoor signage bonding, billboard mounting, furniture assembly, and more
  • HANDLES HIGH TEMPERATURES: Suitable for short-term use at a temperature up to 300 °F (149 °C) or long-term use withstanding up to 200 °F (93 °C)
Spec Sheet



Downloads

Specifications

Shelf Life547
Back Side Adhesive Thickness (Imperial)3.75
Back Side Adhesive Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Face Side Adhesive Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.012
Maximum Operating Temperature (Fahrenheit)300.0
Overall Width (Metric) UOMmm
Number of Adhesive SidesDouble-sided
Backing (Carrier) MaterialPET
Overall Length (Imperial)54.7
Overall Length (Metric) UOMm
IndustriesAppliance, Converter Solutions, Craft, General Industrial, MRO, Metalworking, Point of Purchase, Print, Signage, Specialty Vehicles
Back Side Adhesive Thickness (Metric)0.095
Primary Liner58# Polycoated Kraft Paper (PCK)
Primary Liner ColorWhite
Total Tape Thickness without Liner (Imperial)8.0
Overall Length (Imperial) UOMyd
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Backing (Carrier) Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Country of OriginPoland
Product ColorTransparent
Total Tape Thickness without Liner (Metric)0.2
Face Side Adhesive Thickness (Imperial) UOMmil
Shelf Life UOMMonth
Minimum Operating Temperature (Celsius)-40.0
Primary Liner Thickness (Imperial)3.9
Minimum Operating Temperature (Celsius) UOMDegree
Overall Width (Imperial) UOMin
Face Side Adhesive Thickness (Metric)0.095
Maximum Operating Temperature (Celsius) UOMDegree
Overall Length (Metric)50.0
Backing (Carrier) Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Celsius)149.0
Face Side Adhesive Thickness (Imperial)3.75
Overall Width (Metric)1540.0
Primary Liner Thickness (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit)-40.0
Indoor/OutdoorIndoor/Outdoor
Overall Width (Imperial)60.6
Units per Case1.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Back Side Adhesive Thickness (Imperial) UOMmil
Primary Liner Thickness (Metric)0.1
Primary Liner Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Imperial)0.47
Adhesive TypeModified Acrylic
ApplicationAssembling; Attaching; Bonding; High Strength Adhesion; High Tack Adhesion; Holding; Joining; Laminating; Mounting; Splicing; Tabbing
