3M Products & Supplies

Scotch® Super 33+ Vinyl Electrical Tape, 1 in x 36 yd, Black, 48 rolls/Case - 7000043003

Sold As: 48-Pack
SKU: 7000043003
MPN: 7000043003
For an accurate lead time please contact us
UPC: 00054007089490
3M ID: 80014001020
5 Digit UPC: 8949
$922.75 ($19.22 / Count)
Hurry up! Current stock:

Product Description

Scotch® Super 33+ Vinyl Electrical Tape is a 7 mil thick, premium grade tape that provides electrical insulation for all wires and cables rated up to 600V. The flame retardant tape withstands a temperature range of 0 to 221 °F ( 18 to 105 °C). It is compatible with solid dielectric cable insulation, synthetic cable insulations, jackets and splicing compounds.

Features

  • Withstands a temperature range of 0 to 221 °F (-18 to 105 °C)
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant
  • Flame-retardant and inhibits the corrosion of electrical conductors
  • Made of durable PVC
  • Resists UV rays, abrasion, moisture, alkalis, solvents and acids
  • The combination of the pressure-sensitive, rubber-resin adhesive and the PVC backing offers electrical and mechanical protection
  • Compatible with rubber and synthetic splicing compounds

Downloads

Specifications

Minimum Operating Temperature (Celsius)-18 Degree Celsius
Overall Length (Imperial)36 yd
Overall Length (Metric)33 m
Product MarketsElectrical Equipment Manufacturing
Maximum Operating Temperature (Celsius)105 Degree Celsius
Maximum Operating Temperature (Fahrenheit)221 Degree Fahrenheit
Adhesive TypeRubber
Overall Width (Imperial)1 in
Insulation Resistance> 10^6 megohms
ApplicationInsulation
Overall Width (Metric)25.4 mm
Specifications MetIEC 60454-3-1-7/F-PVC P/90 - VDE Marks License - CSA Certified - UL Listed
Voltage Rating600 V
Tape GradePremium
Backing MaterialPolyvinyl Chloride
UL ApprovalYes
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Chemical ResistantYes
Flame RetardantYes
Maximum Operating Temperature105 °C
Total Tape Thickness without Liner (Imperial)7 mil
Tensile Strength (Metric)26 N/10mm
Suitable for High VoltageNo
Total Thickness0.18 mm
UV ResistantYes
Total Tape Thickness without Liner (Metric)0.178 mm
Adhesion to Steelen-CA: 28 oz/in. - en-US: 28 oz/in. - fr-CA: 28 oz/in.
Elongation at Break250%
VulcanizingNo
Product TypeVinyl Electrical Tapes
Self-extinguishingYes
Color FamilyBlack
