3M Products & Supplies

3M™ Adhesive Transfer Tape 9485EK, Clear, 3/4 in x 180 yd 5 mil, 12 Roll/ Case - 7000049218

Sold As: 12-Pack
SKU: 7000049218
MPN: 7000049218
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051115248245
3M ID: 70006415767
5 Digit UPC: 24824
$1,822.87 ($151.91 / Count)
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape 9485EK leverages the power of 3M™ High Performance Acrylic Adhesive 350 and is mounted on a white, 78 lb. extensible kraft paper liner for ease of processing. This transfer tape is an excellent solution bonding high and low surface energy materials. It can also be used for joining materials that have rougher surfaces.

Features

  • Low odor for improved working environment
  • 5.0 mils (.127 mm) thick tape provides high bond to low surface energy substrates and powder coated paints
  • Excellent chemical resistance and shear and peel strength even at elevated temperatures
  • Designed for short term temperature exposure up to 450°F (232°C) and long term 300°F (149°C)
  • 78 lb. extensible kraft paper liner for additional strength in narrow width automated dispensing applications
  • Adhesive is fiber reinforced for roll stability in narrow widths and to resist oozing
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Imperial)0.75
Primary Liner78# Extensible Polycoated Kraft Paper
Overall Length (Imperial)180.0
Units per Case12.0
Overall Width (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Imperial)5.0
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Metric)19.05
Units per Case UOMRoll
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric)0.127
Overall Length (Metric)164.59
Adhesive TypeAcrylic
IndustriesAppliance, Automotive, Converter Solutions, Electronics, General Industrial, Medical, Metalworking, Military and Government, Oil & Gas, Signage, Specialty Vehicles, Transportation
Overall Length (Metric) UOMm
Primary Liner Thickness (Metric) UOMmm
Primary Liner Thickness (Imperial)6.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner Thickness (Imperial) UOMnone
Minimum Operating Temperature (Fahrenheit)-40.0
Primary Liner Thickness (Metric)0.15
Maximum Operating Temperature (Fahrenheit)450.0
Overall Width (Imperial) UOMin
Primary Liner ColorWhite
