3M Products & Supplies

3M™ Adhesive Transfer Tape 950, Clear, 0.37 in x 180 yd, 5 Mil, 24/Case - 7010372139

Sold As: 24-Pack
SKU: 7010372139
MPN: 7010372139
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200160271
3M ID: 70006062239
5 Digit UPC: 16027
$1,405.89 ($58.58 / Count)
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape 950 is a 300 high strength acrylic adhesive on a 3.5 mil, 60 lb densified kraft paper liner.

Features

  • Thicker version of 927
  • Good UV resistance. Good chemical resistance. Ideal for high surface energy (HSE) and low surface energy (LSE) materials.
  • Used as a general purpose transfer tape for a variety of high tack, thin applications. Ideal for a wide variety of similar and dissimilar materials where an aggressive adhesive with high initial adhesion is desired. Splicing of film, foils, fabrics. Laminating foams, photos, fabrics, metal or plastic nameplates.
  • 5.0 mil adhesive transfer tape. 60 lb densified kraft paper liner. For a wide variety of materials. 300 high strength acrylic adhesive. UL approved. Meets US government specification MIL-P-19834B, Amendment 1.
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Total Tape Thickness without Liner (Metric) UOMmm
Secondary Liner Thickness (Imperial) UOMmil
Number of Adhesive SidesDouble-sided
Overall Width (Imperial) UOMin
Minimum Operating Temperature (Celsius)-40.0
Primary Liner Thickness (Imperial)3.2
Overall Length (Imperial)180.0
Product ColorTranslucent
Secondary Liner Thickness (Imperial)3.0
Total Tape Thickness without Liner (Metric)0.127
Adhesive TypeHigh Strength Acrylic Adhesive 300
Specifications MetUL 969
Overall Width (Metric)9.398
Shelf Life UOMMonth
Backing (Carrier) Thickness (Metric) UOMmm
Units per Case24.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner Thickness (Metric)0.08
Minimum Operating Temperature (Celsius) UOMDegree
Primary Liner Thickness (Metric) UOMmm
Secondary Liner Thickness (Metric)0.07
Indoor/OutdoorIndoor/Outdoor
Minimum Operating Temperature (Fahrenheit)-40.0
Overall Length (Metric)164.59
ApplicationBonding; Commerical Signs; Core Starting; Emblem Attachment; Flying splices for commercial printing; Gasket Assembly; Interior Gasket & Seal Attachment; Large Surface Lamination Assembly; Overlap Splice; Zero-Speed and General Splicing
Primary Liner Thickness (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Metric) UOMmm
Overall Length (Metric) UOMm
Primary Liner ColorTan
Secondary Liner58# Polycoated Kraft Paper
Secondary Liner Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)250.0
Primary LinerGlassine Paper
Units per Case UOMRoll
Total Tape Thickness without Liner (Imperial)5.0
Overall Length (Imperial) UOMyd
IndustriesAppliance, Converter Solutions, Craft, Electronics, Furniture, General Industrial, Medical, Packaging, Paper, Point of Purchase, Print, Signage, Transportation, Woodworking
Secondary Liner ColorTan
Overall Width (Imperial)0.37
Backing (Carrier) Thickness (Metric)0.13
Total Tape Thickness without Liner (Imperial) UOMmil
