3M Products & Supplies

3M™ Adhesive Transfer Tape 966, Clear, 48 in x 60 yd, 2.3 Mil, 1/Case - 7010334498

SKU: 7010334498
MPN: 7010334498
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051115256059
3M ID: 70006429818
5 Digit UPC: 25605
$1,440.22 each
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape 966 leverages the power of 3M™ High Temperature Acrylic Adhesive 100 to produce an excellent high temperature, high strength and chemical resistant bond suitable to the demands of aerospace, automotive and electronics markets. It provides low outgassing properties necessary to deliver optimal performance in demanding applications.

Features

  • Short term temperature tolerance of up to 450 °F (232 °C)
  • Low outgassing properties benefit aerospace, automotive and electronics industries
  • Outstanding UV and chemical resistance for performance longevity
  • Transparent, double sided, 2 mil (0.05 mm) adhesive transfer tape offers a thin profile combined with our high temperature acrylic adhesive for a long-lasting bond
  • 62# densified kraft paper release liner reduces edge burr in hand tool processing of metal plates
  • High peel and shear strength creates bonds suitable for extreme conditions
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Secondary Liner Thickness (Metric) UOMmm
Minimum Operating Temperature (Celsius) UOMDegree
Overall Length (Metric) UOMm
Primary LinerPET
ApplicationArchitectural Panel; Bonding; Commerical Signs; Interior Mirror & Fixture Attachment; Large Surface Lamination Assembly; Mounting & Trim Attachment; Trim & Molding Attachment
Minimum Operating Temperature (Celsius)-40.0
Overall Width (Imperial)48.0
Total Tape Thickness without Liner (Imperial)2.3
Indoor/OutdoorIndoor/Outdoor
Maximum Operating Temperature (Fahrenheit) UOMDegree
Shelf Life UOMMonth
Specifications MetUL 969
Units per Case1.0
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.058
Minimum Operating Temperature (Fahrenheit)-40.0
Primary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Product ColorTranslucent
Primary Liner Thickness (Imperial) UOMmil
Overall Length (Metric)54.86
Primary Liner Thickness (Imperial)3.6
Secondary Liner58# Polycoated Kraft Paper
Minimum Operating Temperature (Fahrenheit) UOMDegree
Secondary Liner Thickness (Imperial) UOMmil
Primary Liner Thickness (Metric)0.09
Maximum Operating Temperature (Celsius) UOMDegree
Primary Liner ColorTransparent
Secondary Liner ColorTan
Overall Width (Metric)1219.2
Overall Length (Imperial) UOMyd
Number of Adhesive SidesDouble-sided
Units per Case UOMRoll
Overall Width (Imperial) UOMin
Secondary Liner Thickness (Imperial)4.2
Maximum Operating Temperature (Fahrenheit)450.0
Maximum Operating Temperature (Celsius)232.0
Total Tape Thickness without Liner (Imperial) UOMmil
Adhesive TypeHigh Temperature Acrylic Adhesive 100
IndustriesAerospace, Appliance, Automotive, Converter Solutions, Electronics, General Industrial, Medical, Signage, Specialty Vehicles, Transportation
Secondary Liner Thickness (Metric)0.107
Product CategoryAdhesives
Overall Length (Imperial)60.0
