3M Products & Supplies

3M™ Cushion-Mount™ Plus Plate Mounting Tape E1720, Teal, 54 in x 36 yd, 20 mil, 1 Roll/Case - 7100312135

SKU: 7100312135
MPN: 7100312135
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060005410
3M ID: 70007558706
$2,768.39 each
Hurry up! Current stock:

Product Description

3M™ Cushion-Mount™ Plus Plate Mounting Tape E1720 with easy mount adhesive is designed for mounting flexographic print plates to cylinders or sleeves. This teal foam mounting tape provides high quality medium firm combination print.

Features

  • Print plates mounted on E1720 will have no air bubbles under the plate due to the air release feature designed into the tape
  • Securely bonds the flexographic photopolymer plate to the print sleeve or steel cylinder to prevent plate edge lifting during printing
  • 0.020 inch (0.51 mm) double coated foam tape has the air release feature with a plate side adhesive technology designed to remove with less force from flexographic print plates
  • Teal foam color indicates the medium firm density foam
  • Grooves in the adhesive are created by a cross-hatch pattern from the release liner
  • Has a medium firm density foam that is ideal for printing combinations of solids and process with halftone dots
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Length (Metric)32.918
Overall Width (Metric)1371.6
Overall Length (Imperial) UOMyd
Overall Length (Imperial)36.0
Overall Length (Metric) UOMm
Product ColorTeal
Overall Width (Imperial) UOMin
IndustriesPrint
Overall Width (Imperial)54.0
Overall Width (Metric) UOMmm
Backing MaterialPolyethylene Foam
Shelf Life UOMMonth
Primary LinerPolycoated Polyester
Adhesive TypeDifferential Acrylate
Primary Liner Thickness (Metric)0.11
Print Quality (Series)17 Series
Application Thickness (Metric) UOMmm
Warranty Period2 Years from Date of Manufacture
Application Thickness (Imperial)20
Clean RemovalYes
Primary Liner Thickness (Metric) UOMmm
Urethane SleevesYes
Print QualityCombination Printing - Medium Firm
Application Thickness (Imperial) UOMmil
Application Thickness (Metric)0.5
