3M™ Cushion-Mount™ Plus Plate Mounting Tape E1920, Pink, 27 in x 36 yd, 20 mil, 1 Roll/Case - 7100312147

SKU: 7100312147
MPN: 7100312147
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060005274
3M ID: 70007558854
$1,306.26 each
Hurry up! Current stock:

Product Description

3M™ Cushion-Mount™ Plus Plate Mounting Tape E1920 with easy mount adhesive is designed for mounting flexographic print plates to cylinders or sleeves. This pink foam mounting tape provides high quality light medium combination print.

Features

  • Has a light medium density foam that is ideal for printing combinations of solids and process with halftone dots
  • 0.020 inch (0.51 mm) double coated foam tape has the air release feature with a plate side adhesive technology designed to remove with less force from flexographic print plates
  • Pink foam color indicates the light, medium density foam
  • E1920 securely bonds the flexographic photopolymer plate to the print sleeve or steel cylinder to prevent plate edge lifting during printing
  • Print plates mounted on E1920 will have no air bubbles under the plate due to the air release feature designed into the tape
  • Grooves in the adhesive are created by a cross-hatch pattern from the release liner
Spec Sheet



Downloads

Specifications

Shelf Life UOMMonth
Overall Width (Imperial) UOMin
Adhesive TypeDifferential Acrylate
Overall Length (Metric)32.918
Overall Length (Imperial)36.0
Overall Length (Metric) UOMm
Backing MaterialPolyethylene Foam
Primary LinerPolycoated Polyester
Overall Width (Metric)685.8
Overall Length (Imperial) UOMyd
Overall Width (Imperial)27.0
Shelf Life730
Product ColorPink
IndustriesPrint
Overall Width (Metric) UOMmm
Country of OriginUnited States
Primary Liner Thickness (Metric) UOMmm
Clean RemovalYes
Urethane SleevesYes
Print Quality (Series)19 Series
Warranty Period2 Years from Date of Manufacture
Print QualityCombination Printing - Light Medium
Primary Liner Thickness (Metric)0.11
Primary Liner Thickness (Imperial)4.5
Application Thickness (Imperial) UOMmil
Application Thickness (Metric) UOMmm
Application Thickness (Metric)0.38
Application Thickness (Imperial)15
Primary Liner Thickness (Imperial) UOMmil
