3M Products & Supplies

3M™ Double Coated Tape 9495LE, Clear, 27 in x 180 yd, 6.7 mil, Roll - 7010535749

Sold As: 2-Pack
SKU: 7010535749
MPN: 7010535749
Made to Order: For a lead time estimate, please send your request to [email protected]
3M ID: CY998785109
5 Digit UPC: #VALUE!
$5,553.46 ($2776.73 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9495LE provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The acrylic adhesive also provides excellent adhesion to surfaces contaminated lightly with oil typically used with machine parts.

Features

  • High bonding strength to LSE plastics
  • Film carrier makes for easy handling during slitting and die-cutting
  • Adds dimensional stability to foams and other substrates and also makes it easier to handle the tape during slitting and die-cutting
  • 3M™ Double Coated Tape 9495LE features a single liner for ease in selective die cutting
  • The bond strength of 3M™ Laminating Adhesive 300LSE increases as a function of time and temperature, and has very high initial adhesion
  • Film carrier adding dimensional stability to foams and other substrates
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Backing (Carrier) Thickness (Metric)0.013
Face Side Adhesive Thickness (Imperial)2.8
Overall Width (Imperial) UOMin
Primary Liner Thickness (Metric)0.11
Backing (Carrier) Thickness (Imperial) UOMmil
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
Face Side Adhesive Thickness (Metric)0.071
Overall Length (Imperial)180.0
Back Side Adhesive Thickness (Metric)0.086
Overall Length (Metric)164.59
Overall Width (Metric)685.8
Back Side Adhesive Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Imperial) UOMmil
Overall Width (Imperial)27.0
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric) UOMmm
Primary Liner Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Metric) UOMmm
Primary Liner Thickness (Metric) UOMmm
Primary Liner ColorTan
Overall Length (Metric) UOMm
Total Tape Thickness without Liner (Metric)0.17
Back Side Adhesive Thickness (Imperial)3.4
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Imperial)6.7
Adhesive TypeLow Surface Energy Acrylic Adhesive 300LSE
Primary Liner Thickness (Imperial)4.2
Product ColorTransparent
Back Side Adhesive Thickness (Imperial) UOMmil
IndustriesElectronics, General Industrial
Primary Liner58# Polycoated Kraft Paper (PCK)
Backing (Carrier) Thickness (Imperial)0.5
Total Tape Thickness without Liner (Imperial) UOMmil
Backing (Carrier) MaterialPET
