3M Products & Supplies

3M™ Double Coated Tape 9495LE, Clear, 27 in x 180 yd, 5.9 mil, 1 Roll/Case - 7000048873

SKU: 7000048873
MPN: 7000048873
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 50021200432519
3M ID: 70006280401
5 Digit UPC: 43251
$2,776.73 each
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9495LE provides high bond strength to most surfaces, including many low surface energy plastics such as polypropylene and powder coated paints. The acrylic adhesive also provides excellent adhesion to surfaces contaminated lightly with oil typically used with machine parts.

Features

  • Adds dimensional stability to foams and other substrates and also makes it easier to handle the tape during slitting and die-cutting
  • The bond strength of 3M™ Laminating Adhesive 300LSE increases as a function of time and temperature, and has very high initial adhesion
  • Film carrier makes for easy handling during slitting and die-cutting
  • High bonding strength to LSE plastics
  • 3M™ Double Coated Tape 9495LE features a single liner for ease in selective die cutting
  • Film carrier adding dimensional stability to foams and other substrates
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Adhesive TypeLow Surface Energy Acrylic Adhesive 300LSE
Backing (Carrier) Thickness (Imperial)0.5
Primary Liner ColorTan
Backing (Carrier) Thickness (Metric)0.013
Overall Length (Metric)164.59
Overall Width (Imperial) UOMin
Back Side Adhesive Thickness (Metric)0.086
Face Side Adhesive Thickness (Imperial) UOMmil
Overall Width (Imperial)27.0
Overall Width (Metric)685.8
Primary Liner Thickness (Imperial)4.2
Overall Length (Imperial)180.0
Overall Length (Imperial) UOMyd
Overall Length (Metric) UOMm
Back Side Adhesive Thickness (Metric) UOMmm
Product CategoryAdhesive Transfer Tapes & Double Coated Tapes
IndustriesElectronics, General Industrial
Total Tape Thickness without Liner (Metric)0.17
Backing (Carrier) Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Metric)0.071
Total Tape Thickness without Liner (Metric) UOMmm
Primary Liner58# Polycoated Kraft Paper (PCK)
Primary Liner Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)6.7
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Metric) UOMmm
Face Side Adhesive Thickness (Imperial)2.8
Back Side Adhesive Thickness (Imperial)3.4
Product ColorTransparent
Primary Liner Thickness (Metric) UOMmm
Backing (Carrier) MaterialPET
Backing (Carrier) Thickness (Metric) UOMmm
Face Side Adhesive Thickness (Metric) UOMmm
Primary Liner Thickness (Metric)0.11
Back Side Adhesive Thickness (Imperial) UOMmil
