3M Products & Supplies

3M™ Double Coated Tape 9500PC, Clear, 1/2 in x 36 yd, 5.6 mil, 72 Roll/Case - 7000123416

Sold As: 72-Pack
SKU: 7000123416
MPN: 7000123416
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00021200677953
3M ID: 70006103017
5 Digit UPC: 67795
$1,144.87 ($15.90 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9500PC is a 5 mil (0.14 mm) 350 high performance acrylic adhesive double coat with a thin polyester carrier film on a 58#, 4.5 mil unprinted, polycoated kraft paper liner. The adhesive excels on low surface energy (LSE) substrates and at high temps.

Features

  • 58# unprinted polycoated kraft liner reduces edge burr during hard tool die cutting
  • High-holding strength and short-term heat resistance up to 350°F (177°C)
  • 1.0 mil, clear PET carrier film for dimensional stability and ease of die cutting
  • Clear, 5 mil (0.14 mm) double coated tape with high performance acrylic
  • Adheres to powder coated surfaces, most plastics and difficult surfaces
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Overall Width (Metric) UOMmm
Minimum Operating Temperature (Celsius)-40.0
Back Side Adhesive Thickness (Metric) UOMmm
Overall Width (Imperial) UOMin
Product ColorTransparent
Overall Width (Imperial)0.5
Backing (Carrier) MaterialPolyester
Primary Liner Thickness (Imperial)4.5
Backing (Carrier) Thickness (Imperial)1.0
Primary Liner Thickness (Metric) UOMmm
Units per Case72.0
Primary Liner ColorTan
Backing (Carrier) Thickness (Metric) UOMmm
Overall Width (Metric)12.7
Back Side Adhesive Thickness (Imperial)2.3
Primary Liner62# Polycoated Kraft Paper
Maximum Operating Temperature (Celsius) UOMDegree
Back Side Adhesive Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Imperial)2.3
Overall Length (Metric) UOMm
Total Tape Thickness without Liner (Metric) UOMmm
Maximum Operating Temperature (Celsius)177.0
Overall Length (Imperial) UOMyd
Minimum Operating Temperature (Fahrenheit)-40.0
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)5.6
Maximum Operating Temperature (Fahrenheit)350.0
Primary Liner Thickness (Metric)0.11
Face Side Adhesive Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.025
Back Side Adhesive Thickness (Metric)0.058
Face Side Adhesive Thickness (Imperial) UOMmil
Indoor/OutdoorIndoor/Outdoor
Primary Liner Thickness (Imperial) UOMmil
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric)32.91
IndustriesAutomotive, Converter Solutions, Electronics, General Industrial, Medical, Metalworking, Military and Government, Oil & Gas, Signage, Specialty Vehicles, Transportation
Total Tape Thickness without Liner (Metric)0.14
Overall Length (Imperial)36.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Face Side Adhesive Thickness (Metric)0.058
Backing (Carrier) Thickness (Imperial) UOMmil
Minimum Operating Temperature (Celsius) UOMDegree
