3M Products & Supplies

3M™ Double Coated Tape 9731, Clear, 2 in x 108 yd, 5.5 mil, 6 Roll/Case - 7010373709

Sold As: 24-Pack
SKU: 7010373709
MPN: 7010373709
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138965266
3M ID: 70006398872
5 Digit UPC: 96526
$21,463.08 ($894.30 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9731 was developed with a high-performance acrylic adhesive on the face side and a silicone adhesive on the liner side of a 1 mil clear PET carrier. It is excellent for demanding applications where silicone materials must be bonded to a range of substrates.

Features

  • 3M™ Adhesive 350 on the face side provides exceptional temperature and chemical resistance
  • Features acrylic and silicone adhesives for specialized applications such as silicone gasketing
  • Double linered – Adhesive 350 on 58# 4.2 mil PCK liner and silicone adhesive on 3 mil PET liner
  • 3 mil silicone adhesive on liner side bonds well to silicone substrates
  • Ideal for attaching silicone rubber elastomers and foam
Spec Sheet



Downloads

Specifications

Shelf Life547
Country of OriginUnited States
Core Size (Imperial)3.0
Back Side Adhesive Thickness (Imperial)2.9
Overall Thickness (Imperial) UOMmil
Overall Length (Imperial) UOMyd
Tape TypeDouble Coated
Back Side Adhesive TypeSilicone
Core Size (Metric) UOMmm
Primary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Imperial)5.5
Shelf Life in Months (From Date of Manufacture)12.0
Shelf Life in Months (From Date of Manufacture) UOMMonths
Secondary Liner Thickness (Metric)0.07
Carrier Thickness (Metric) UOMmm
Secondary Liner Thickness (Imperial)2.9
Carrier MaterialPolyester Film
Master Size Width (Metric) UOMcm
Master Size Length (Metric)98.8
Face Side Adhesive Thickness (Metric)0.041
Overall Thickness (Imperial)5.5
Adhesive TypeAcrylic/Silicone
Backing (Carrier) MaterialPolyester Film
Core Size (Imperial) UOMin
Maximum Operating Temperature (Fahrenheit)250.0
Overall Length (Imperial)108.0
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Metric)50.8
Maximum Operating Temperature (Fahrenheit) UOMDegree
Face Side Adhesive TypeHigh Performance Acrylic Adhesive 350
Overall Width (Metric) UOMmm
Back Side Adhesive Thickness (Imperial) UOMmil
Overall Length (Metric)98.76
Minimum Operating Temperature (Fahrenheit)-40.0
Back Side Adhesive Thickness (Metric) UOMmm
Primary Liner Thickness (Imperial)4.2
Overall Length (Metric) UOMm
Backing (Carrier) Thickness (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial) UOMmil
Core Size (Metric)76.2
Face Side Adhesive Thickness (Imperial)1.6
Product FormRoll
Primary Liner58# Polycoated Kraft Paper (PCK)
Shelf Life UOMMonth
Assembly TypeGasket Attachment
Carrier Thickness (Metric)0.03
Face Side Adhesive Thickness (Metric) UOMmm
IndustriesMetalworking, Signage, Specialty Vehicles
Indoor/OutdoorBoth
Overall Width (Imperial) UOMin
Backing (Carrier) Thickness (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius)-40.0
Master Size Width (Metric)122.0
Primary Liner Thickness (Metric)0.17
Maximum Operating Temperature (Celsius)121.0
Backing (Carrier) Thickness (Metric)0.025
Overall Width (Imperial)2.0
Face Side Adhesive Thickness (Imperial) UOMmil
Primary Liner Thickness (Imperial) UOMmil
Minimum Operating Temperature (Celsius) UOMDegree
Product ColorTransparent
Master Size Length (Metric) UOMm
Backing (Carrier) Thickness (Imperial)1.0
Total Tape Thickness without Liner (Metric)0.14
Secondary Liner Thickness (Imperial) UOMmil
Secondary Liner Thickness (Metric) UOMmm
Primary Liner ColorTan
Carrier Thickness UOMmil
Carrier Thickness0.09513889
