3M Products & Supplies

3M™ Double Coated Tape 9737, Clear, 36 mm x 55 m, 3.5 mil, 32 Roll/Case - 7000124329

Sold As: 32-Pack
SKU: 7000124329
MPN: 7000124329
For an accurate lead time please contact us
UPC: 00051115314643
3M ID: 70006434891
5 Digit UPC: 31464
$526.18 ($16.44 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9737 Red is a double-sided tape mounted on a thin polyester carrier with a pressure sensitive acrylic adhesive that offers a balance of high initial adhesion and good holding power. It is mounted on 55 lb. densified kraft paper liner for easy release and manipulation during application.

Features

  • High tack acrylic adhesive performs well across broad temperature range
  • Good moisture resistance to ensure performance in a variety of situations
  • Versatile adhesion bonds well to kraft and coated papers, as well plastic
  • Available in red
  • Ideal performance in high speed splicing applications
  • Excellent peel, tack and shear strength to withstand rigorous splicing applications
Spec Sheet



Downloads

Specifications

Shelf Life365
Country of OriginUnited States
Primary Liner55# Densified Kraft Paper (DK)
Backing (Carrier) Thickness (Imperial)0.5
Overall Width (Imperial) UOMin
Carrier MaterialPolyester Film
Overall Width (Metric) UOMmm
ApplicationZero-Speed and General Splicing
Tape TypeDouble Coated
Carrier Thickness (Metric)0.0127
IndustriesAppliance, Automotive, Electronics, General Industrial, Medical, Specialty Vehicles, Transportation
Overall Length (Imperial)60.15
Product FormRoll
Maximum Operating Temperature (Fahrenheit)300.0
Product ColorTransparent
Total Tape Thickness without Liner (Metric)0.089
Backing (Carrier) Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Imperial) UOMmil
Number of Adhesive SidesDouble-sided
Carrier Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Primary Liner ColorWhite
Overall Width (Metric)36.0
Total Tape Thickness without Liner (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.0127
Overall Length (Metric)55.0
Overall Width (Imperial)1.42
Backing (Carrier) Thickness (Imperial) UOMmil
Backing (Carrier) MaterialPolyester Film
Total Tape Thickness without Liner (Imperial)3.5
Units per Case32.0
Overall Length (Metric) UOMm
Overall Length (Imperial) UOMyd
Carrier Thickness UOMmil
Carrier Thickness0.5
