3M Products & Supplies

3M™ Electrically Conductive Single-Sided Tape 1020BC-25, Black, 500 mm x 30 m, 1 Roll/Case - 7100313408

SKU: 7100313408
MPN: 7100313408
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00068060428110
3M ID: 80001605023
$804.61 each
Hurry up! Current stock:

Product Description

3M™ Electrically Conductive Single-Sided Tape 1020BC Series is an XYZ-axis electrically conductive pressure sensitive adhesive (CPSA) tape that helps enable devices to meet electromagnetic compatibility requirements. It consists of a conductive black copper foil backing, a conductive acrylic adhesive layer and a polyester (PET) release liner. This black copper foil tape provides excellent XYZ-axis-based conductivity, reliable contacts to small-size grounding areas and excellent EMI shielding and electrical reliability over time. The thin profile makes it a great option for applications with less Z-space. It offers high adhesion and good grounding performance to many surface types.

Features

  • Low electrical resistance
  • Excellent conformability and quick bonding
  • Stiffer copper for improved workability
  • Sleek black conductive coating
  • Excellent EMI shielding performance
  • XYZ-axis conductivity
Spec Sheet



Downloads

Specifications

Shelf Life12.0 Month
Country of OriginSouth Korea
Minimum Operating Temperature (Fahrenheit)-40.0 Degree Fahrenheit
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Backing (Carrier) MaterialCopper Foil
Overall Length (Imperial) UOMyd
Minimum Operating Temperature (Celsius)-40.0 Degree Celsius
Overall Width (Imperial)19.685
Product UsageCamera Modules; Display Chip on Flex; Display Wraps; EMI Shields; Printed Circuit Boards; Sensors
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)0.984
Adhesion Strength (Imperial)1300.0
Maximum Operating Temperature (Fahrenheit)250.0 Degree Fahrenheit
Overall Width (Metric)500.0
Maximum Operating Temperature (Celsius)121.0 Degree Celsius
Total Tape Thickness without Liner (Metric)0.025
ApplicationEMI Shielding; Passive Intermodulation (PIM) Management
Overall Length (Metric) UOMm
Liner MaterialPET
Overall Length (Metric)30.0
Product ColorBlack
Adhesive TypeAcrylic
Overall Length (Imperial)32.808
Electrical ResistanceXY-axis 0.015 Ω, Z-axis 0.1 Ω
Overall Width (Imperial) UOMin
