3M Products & Supplies

3M™ EMI Aluminum Foil Shielding Tape 1170, 25 mm x 16.5 m, 3 in Paper Core, 9 Rolls/Case - 7100033111

Sold As: 9-Pack
SKU: 7100033111
MPN: 7100033111
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00076308623357
3M ID: 80000208423
5 Digit UPC: 62335
$810.94 ($90.10 / Count)
Hurry up! Current stock:

Product Description

3M™ Aluminium Foil EMI Shielding Tape 1170 is an acrylic adhesive, EMI shielding foil tape. This flame retardant tape is designed for applications that require reliable, point to point electrical contact. It comes on a removable liner for easy die cutting and handling. It withstands a wide temperature range of -40°C to 130°C (-40°F to 266°F). The tape is rated for 600V dry applications.

Features

  • Suitable for EMI shielding, grounding and static charge draining
  • Typical shielding effectiveness is above 85 dB, 1MHz to GHz
  • Flame-retardant
  • Rated for 600V applications
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Unique adhesive creates secure contact with the application surface
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginTaiwan
Overall Width (Metric)25.0
Tensile Strength (Imperial) UOMlb/in
Tensile Strength (Imperial)20.0
Specifications MetRoHS 2011/65/EU, UL Recognized
Backing (Carrier) Thickness (Metric) UOMmm
Overall Length (Imperial) UOMyd
Maximum Operating Temperature (Fahrenheit)266.0
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Width (Imperial) UOMin
Product MarketsElectrical Equipment Manufacturing
Minimum Operating Temperature (Fahrenheit)-40.0
Backing MaterialAluminum; Aluminum Foil
Minimum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Celsius)130.0
Minimum Operating Temperature (Celsius)-40.0
Overall Width (Metric) UOMmm
Backing (Carrier) Thickness (Imperial)2.0
Backing (Carrier) Thickness (Metric)0.051
Shelf Life UOMYear
Overall Length (Metric) UOMm
ApplicationShielding
Backing (Carrier) MaterialAluminum
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric)16.5
Overall Length (Imperial)18.0
Maximum Operating Temperature (Celsius) UOMDegree
Adhesive TypeConductive Acrylic
IndustriesElectronics
Product ColorSilver
Shielding Effectiveness75.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Imperial)0.98
