3M Products & Supplies

3M™ Filament-Reinforced Electrical Tape 46, 1/4 in x 60 yd, Translucent, 144 Rolls/Case - 7010398738

Sold As: 144-Pack
SKU: 7010398738
MPN: 7010398738
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138528034
3M ID: 80610870109
5 Digit UPC: 52803
$1,475.82 ($10.25 / Count)
Hurry up! Current stock:

Product Description

3M™ Tape 46 is an electrical tape with rubber adhesive. This tape is ideal for anchoring lead wires to banding coils and for end turn taping. This tape is 600V rated and withstands a temperature range of 32 to 266 °F (0 to 130 °C).

Features

  • Low stretch, high tensile and edge-tear resistance
  • Excellent for anchoring lead wires to banding coils and end-turn taping
  • Tough, durable filament tape with thermosetting rubber resin adhesive
  • UL Listed and RoHS 2011/65/EU Compliant
  • For applications needing both the dielectric strength of polyester film and the high mechanical strength of glass fibers
  • 7 mil thickness
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginUnited States
Tensile Strength (Metric) UOMN/10mm
Overall Width (Metric) UOMmm
Overall Length (Metric)54.8
Adhesive TypeThermosetting Rubber
Overall Width (Metric)6.35
Insulation Resistance> 10^6 megohms
Overall Length (Imperial) UOMyd
Elongation at Break5
Tensile Strength (Metric)481.0
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Metric) UOMmm
Overall Length (Imperial)60.0
Shelf Life UOMYear
ApplicationInsulation
Overall Width (Imperial)0.25
Tensile Strength (Imperial)275.0
Product ColorTransparent
Total Tape Thickness without Liner (Imperial)7.0
Total Tape Thickness without Liner (Imperial) UOMmil
Tensile Strength (Imperial) UOMlb/in
Total Tape Thickness without Liner (Metric)0.178
Electrolytic Corrosion Factor1.0
Overall Length (Metric) UOMm
Specifications MetCSA Certified, UL Recognized
