3M Products & Supplies

3M™ Filament-Reinforced Electrical Tape 46, 1/8 in x 60 yds, 3 in plastic core, 288 Rolls/Case - 7010399164

Sold As: 288-Pack
SKU: 7010399164
MPN: 7010399164
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128540152
3M ID: 80611233257
5 Digit UPC: 54015
$2,673.31 ($9.28 / Count)
Hurry up! Current stock:

Product Description

3M™ Tape 46 is an electrical tape with rubber adhesive. This tape is ideal for anchoring lead wires to banding coils and for end turn taping. This tape is 600V rated and withstands a temperature range of 32 to 266 °F (0 to 130 °C).

Features

  • For applications needing both the dielectric strength of polyester film and the high mechanical strength of glass fibers
  • Tough, durable filament tape with thermosetting rubber resin adhesive
  • Excellent for anchoring lead wires to banding coils and end-turn taping
  • Low stretch, high tensile and edge-tear resistance
  • 7 mil thickness
  • UL Listed and RoHS 2011/65/EU Compliant

Specifications

Shelf Life1825
Country of OriginUnited States
Total Tape Thickness without Liner (Imperial)7.0
Total Tape Thickness without Liner (Imperial) UOMmil
Elongation at Break5
Tensile Strength (Imperial) UOMlb/in
Electrolytic Corrosion Factor1.0
Specifications MetCSA Certified, UL Recognized
Overall Width (Imperial)0.0
Tensile Strength (Metric) UOMN/10mm
Total Tape Thickness without Liner (Metric) UOMmm
Adhesive TypeThermosetting Rubber
Overall Width (Metric)3.175
ApplicationInsulation
Overall Width (Metric) UOMmm
Tensile Strength (Metric)481.0
Tensile Strength (Imperial)275.0
Product ColorTransparent
Total Tape Thickness without Liner (Metric)0.178
Shelf Life UOMYear
Insulation Resistance> 10^6 megohms
