3M Products & Supplies

3M™ Heat Shrink Thin-Wall Tubing FP-301-1/16-Red-1000`: 1000 ft spool length, 3000 ft/box, 3 Rolls/Case - 7010396206

Sold As: 3000-Pack
SKU: 7010396206
MPN: 7010396206
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007084631
3M ID: 80610219315
5 Digit UPC: 8463
$1,488.03 ($0.50 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Minimum Expanded Tubing I. D. UOMin
Overall Length (Imperial)1000.0
ApplicationElectrical Insulation; High-tenacity and chemically resistant tubing
Maximum Operating Temperature (Fahrenheit)275.0
Operating Temperature (Celsius)-55 to 135 Degrees Celsius
Inner Diameter After Shrink (Metric) UOMmm
Product ColorRed
Maximum Operating Temperature (Celsius) UomDegree
Inner Diameter After Shrink (Imperial)0.031
Heat Shrink TypeSingle-Wall Polyolefin Heat Shrink Tubing
Elongation UOM%
Flame RetardantYes
Maximum Operating Temperature (Fahrenheit) UOMDegree
Mil SpecAMS-DTL-23053/5, Class 1
Overall Length (Imperial) UOMft
Inner Diameter Before Shrink (Metric)1.6
Inner Diameter Before Shrink (Metric) UOMmm
Inner Diameter Before Shrink (Imperial)0.063
Minimum Expanded Tubing I. D.1.0
Inner Diameter After Shrink (Imperial) UOMin
MaterialFlexible Polyolefin
Adhesive MaterialNone
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Inner Diameter Before Shrink (Imperial) UOMin
UL File NumberE-39100
Shrink Ratio2:1
Maximum Operating Temperature (Celsius)135.0
Non-CorrosiveYes
Inner Diameter After Shrink (Metric)0.79
Tubing TypeSingle (Thin) Wall
