3M Products & Supplies

3M™ Heat Shrink Thin-Wall Tubing FP-301-1.5-White-100', 100 ft Length per spool, 76200 Meter/Case - 7000057974

Sold As: 200-Pack
SKU: 7000057974
MPN: 7000057974
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007085157
3M ID: 80610219836
5 Digit UPC: 8515
$542.66 ($2.71 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Inner Diameter After Shrink (Metric)19.05
Inner Diameter After Shrink (Imperial)0.75
Non-CorrosiveYes
Heat Shrink TypeSingle-Wall Polyolefin Heat Shrink Tubing
Shrink Ratio2:1
Maximum Operating Temperature (Fahrenheit)275.0
Mil SpecAMS-DTL-23053/5, Class 1
ApplicationElectrical Insulation; High-tenacity and chemically resistant tubing
Inner Diameter After Shrink (Metric) UOMmm
Inner Diameter After Shrink (Imperial) UOMin
Elongation UOM%
Inner Diameter Before Shrink (Imperial) UOMin
Overall Length (Imperial)100.0
Tubing TypeSingle (Thin) Wall
Units per Case2.0
Flame RetardantYes
Maximum Operating Temperature (Celsius)135.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Inner Diameter Before Shrink (Imperial)1.5
Inner Diameter Before Shrink (Metric) UOMmm
Adhesive MaterialNone
Operating Temperature (Celsius)-55 to 135 Degrees Celsius
Product ColorWhite
UL File NumberE-39100
Inner Diameter Before Shrink (Metric)38.1
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Celsius) UomDegree
Overall Length (Imperial) UOMft
