3M Products & Supplies

3M™ Heat Shrink Thin-Wall Tubing FP-301, Clear, 3/32, 100 ft spool length, 300 ft/case - 7100030622

Sold As: 300-Pack
SKU: 7100030622
MPN: 7100030622
For an accurate lead time please contact us
UPC: 10076308624108
3M ID: 80610752190
5 Digit UPC: 62410
$186.08 ($0.62 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

  • HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
  • FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
  • KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant
  • A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
  • FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Inner Diameter Before Shrink (Imperial)0.093
Operating Temperature (Celsius)-55 to 135 Degrees Celsius
Mil SpecSAE-AMS-DTL-23053/5, Class 2
Overall Length (Imperial)100.0
Overall Length (Imperial) UOMft
Maximum Operating Temperature (Celsius)135.0
Adhesive MaterialNone
Minimum Expanded Tubing I. D.0.093
Units per Case3.0
Overall Length (Metric)30.5
Product ColorTransparent
Non-CorrosiveYes
MaterialFlexible Polyolefin
Inner Diameter Before Shrink (Metric) UOMmm
Inner Diameter After Shrink (Metric)1.17
Operating Temperature Range (Fahrenheit)-67 °F to 275 °F
Flame RetardantNo
Inner Diameter After Shrink (Imperial)0.046
Shrink Ratio2:1
Elongation UOM%
Maximum Operating Temperature (Fahrenheit)275.0
UL File NumberE-39100
Operating Temperature Range (Celsius)-55 °C to +135 °C
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
UL ApprovalYes
Inner Diameter Before Shrink (Imperial) UOMin
ApplicationElectrical Insulation; High-tenacity and chemically resistant tubing
Overall Length (Metric) UOMm
Operating Temperature (Fahrenheit)-67 °F to 275 °F
Maximum Operating Temperature (Fahrenheit) UOMDegree
Inner Diameter After Shrink (Imperial) UOMin
Minimum Shrink Temperature (Celsius)100.0
Inner Diameter Before Shrink (Metric)2.36
Product FormSpool
Maximum Operating Temperature (Celsius) UomDegree
Inner Diameter After Shrink (Metric) UOMmm
Minimum Expanded Tubing I. D. UOMin
Tubing TypeSingle Wall (Thin)
Heat Shrink TypeSingle-Wall Polyolefin Heat Shrink Tubing
