3M™ Heat Shrink Thin-Wall Tubing FP-301-3/64-Clear-100`: 100 ft spool length, 300 ft/case - 7010319286

Name: 3M™ Heat Shrink Thin-Wall Tubing FP-301-3/64-Clear-100`: 100 ft spool length, 300 ft/case - 7010319286
Brand: 3M Products & Supplies
SKU: 7010319286
Price: 372.7 USD
Availability: InStock

Sold As: 600-Pack

SKU: 7010319286

MPN: 7010319286

Made to Order: For a lead time estimate, please send your request to [email protected]

UPC: 10076308623989

3M ID: 80610749121

5 Digit UPC: 62398

$372.70 ($0.62 / Count)

Hurry up! Current stock:

Quantity:

Product Description

3M™ Heat Shrink Tubing FP-301 is a general purpose, thin wall tubing that provides a balance of electrical, physical and chemical properties, making it ideal for industrial and military applications. This tubing has a 2:1 shrink ratio and provides flame retardant insulation for 600V rated applications. It has a flexible polyolefin construction that offers moisture seal protection.

Features

A VARIETY OF APPLICATIONS: Offers a 2:1 shrink-fit ratio and serves as protection in wire-harnessing, split-resistance covering, wire marking, wire bundling, and component packaging
FOR DEMANDING CONDITIONS: Performs at an operating temperature up to 275 °F (135 °C)
FLAME-RETARDANT TUBING: For applications up to 600V (clear is not flame retardant)
HIGH-STRENGTH PROTECTION: Balances electrical, physical, and chemical properties for various industrial and military applications
KEY SPECIFICATIONS: UL Listed, File E-39100, SAE AS23053/5, Class 1 (all colors), Class 2 (clear), CSA Certified, and RoHS 2011/65/EU Compliant

Spec Sheet

Downloads

Spec Sheet

Product Selection Guides

Document Brochures

Specifications

Shelf Life	3600
Country of Origin	United States
Maximum Operating Temperature (Celsius)	135.0
UL File Number	E-39100
Inner Diameter After Shrink (Imperial)	0.023
Inner Diameter Before Shrink (Imperial) UOM	in
Operating Temperature (Celsius)	-55 to 135 Degrees Celsius
Minimum Expanded Tubing I. D.	3.0
RoHS EU Comments	RoHS 2011/65/EU compliant without exemption
Mil Spec	AMS-DTL-23053/5, Class 2
Adhesive Material	None
Inner Diameter After Shrink (Metric)	0.58
Inner Diameter Before Shrink (Metric)	1.17
Overall Length (Imperial) UOM	ft
Inner Diameter After Shrink (Imperial) UOM	in
Inner Diameter After Shrink (Metric) UOM	mm
Maximum Operating Temperature (Fahrenheit) UOM	Degree
Maximum Operating Temperature (Celsius) Uom	Degree
Flame Retardant	No
Overall Length (Imperial)	100.0
Inner Diameter Before Shrink (Imperial)	0.046
Units per Case	3.0
Shrink Ratio	2:1
Minimum Expanded Tubing I. D. UOM	in
Elongation UOM	%
Product Color	Transparent
Non-Corrosive	Yes
Heat Shrink Type	Single-Wall Polyolefin Heat Shrink Tubing
Application	Electrical Insulation; High-tenacity and chemically resistant tubing
Tubing Type	Single (Thin) Wall
Maximum Operating Temperature (Fahrenheit)	275.0
Inner Diameter Before Shrink (Metric) UOM	mm
