3M™ Non-Insulated Butted Seam Ring Tongue Terminal 12-56S, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163580

Sold As: 1000-Pack
SKU: 7100163580
MPN: 7100163580
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007283263
3M ID: 80601380183
MPN: 12-56S
$111.54 ($0.11 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Standard-style ring tongue fits around the stud
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires

Downloads

Specifications

Maximum Conductor Size (Imperial)14 AWG
Maximum Operating Temperature (Celsius)175.0
Maximum Conductor Size (Metric)2.08
Terminal TypeRing
Minimum Conductor Size (Imperial)16 AWG
Minimum Stud Diameter (Metric) UOMmm
Country of OriginUnited States
Connection TypeCrimp
Maximum Operating Temperature (Celsius) UOMDegree
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Barrel StyleBrazed
Minimum Stud Diameter (Metric)7.95
Barrel Length (Imperial)0.25 Inch
Minimum Stud Diameter (Imperial) UOMin
UL File NumberE23438
Terminal StyleStandard
Minimum Conductor Size (Metric)1.31 mm²
Ring TypeStandard
Insulation MaterialNon-insulated
