3M™ Non-Insulated Butted Seam Ring Tongue Terminal, 14185, Max. Temp. 347 °F (175 °C) for bare terminals - 7100163487

Sold As: 1000-Pack
SKU: 7100163487
MPN: 7100163487
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007279266
3M ID: 80601375977
MPN: 11-38
$111.54 ($0.11 / Count)
Hurry up! Current stock:

Product Description

This terminal has a wire range of 8 AWG and a stud size of 1/4. It comes in quantities of 25 per carton and 250 per case.

Features

  • Standard-style ring tongue fits around the stud
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires

Downloads

Specifications

Maximum Operating Temperature (Celsius) UOMDegree
Maximum Conductor Size (Imperial)18 AWG
Minimum Stud Diameter (Imperial) UOMin
Barrel StyleBrazed
Maximum Operating Temperature (Celsius)175.0
Terminal StyleStandard
Minimum Stud Diameter (Metric) UOMmm
UL File NumberE23438
Connection TypeCrimp
Ring TypeStandard
Country of OriginUnited States
Minimum Stud Diameter (Metric)9.525
Barrel Length (Imperial)0.25 Inch
Minimum Conductor Size (Imperial)22 AWG
Terminal TypeRing
Maximum Conductor Size (Metric)0.823
Minimum Conductor Size (Metric)0.326 mm²
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Insulation MaterialNon-insulated
