3M Products & Supplies

3M™ Scotch® Rubber Splicing Tape 23, 38 mm x 9.15 m, 45 Rolls/Case - 7012496304

SKU: 7012496304
MPN: 7012496304
Stock Item: Stock items typically ship within 2-3 business days
UPC: 07891040248148
$2,832.25
Hurry up! Current stock:

Product Description

Scotch® Tape 23 is a 30 mil, premium grade, highly conformable, rubber splicing tape. The self fusing tape has a special polyester liner, which will not stick to the tape upon unwind. It withstands temperatures up to 194 °F (90 °C).

Features

  • Temperature rated for continuous adhesion to 194°F (90°C)
  • ASTM Approved & RoHS 2002/65/EC Compliant
  • Self-fusing, ethylene propylene rubber backing and highly conformable, rubber-resin adhesive
  • Special polyester liner keeps tape protected and clean during application
Spec Sheet



Downloads

Specifications

Rolls per Case45.0
Tensile Strength (Metric)55.0
Overall Width (Imperial)1.496
Dielectric Strength800.0
Adhesive TypeRubber Resin
Insulation Resistance> 10^6 megohms
Overall Width (Imperial) UOMin
Shelf Life1825
Total Tape Thickness without Liner (Imperial)30.0
Overall Length (Metric)9.15
Tensile Strength (Imperial)8.0
Total Tape Thickness without Liner (Imperial) UOMmil
Maximum Operating Temperature (Celsius) UOMDegree
Dielectric Strength UOMV/mil
Total Tape Thickness without Liner (Metric)0.76
FeaturesSelf-sticking; Vulcanizing
Units per Case45.0
Overall Width (Metric)38.0
Maximum Operating Temperature (Fahrenheit)194.0
Overall Length (Imperial)30.0
Tensile Strength (Metric) UOMkPa
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric) UOMm
Shelf Life UOMYear
Minimum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) MaterialEthylene Propylene Rubber
Backing (Carrier) Thickness (Metric)0.76
Product ColorBlack
Product MarketsElectrical Construction
Minimum Operating Temperature (Celsius)0.0
Country of OriginBrazil
Backing (Carrier) Thickness (Metric) UOMmm
Overall Width (Metric) UOMmm
Overall Length (Imperial) UOMft
Elongation at Break800
Application/IndustryCommercial Construction; Industrial Construction; Maintenance and Repair Operations; Mining; Residential Construction; Solar; Wind Power
Maximum Operating Temperature (Celsius)130.0
ApplicationElectrical Maintenance; Insulation; Sealing
Rolls per Carton1.0
Tape GradeProfessional
Total Tape Thickness without Liner (Metric) UOMmm
Tensile Strength (Imperial) UOMlb/in
