3M Products & Supplies

3M™ Scotchlok™ Male Disconnect Nylon Insulated, 100/bottle, MNG18-187DMIX, 500/Case - 7000148857

Sold As: 500-Pack
SKU: 7000148857
MPN: 7000148857
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128588079
3M ID: 80611464530
5 Digit UPC: 58807
$618.09 ($1.24 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Color-Coded Male Disconnect Terminal offers superior holding force while allowing for quick and easy disconnect. The terminal has a fully insulated, nylon, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Allows for quick and easy disconnect of wires
  • Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating
  • This male disconnect terminal offers excellent holding force
  • UL Listed, CSA Certified and RoHS 2011/65/EU Compliant

Downloads

Specifications

Country of OriginUnited States
Pad Width0.187
Maximum Conductor Size (Metric)1 mm²
Bullet Diameter0.156
Connection Width (Imperial) UOMin
Overall Diameter (Imperial)0.3
Barrel Inside Diameter0.145 Inch
Terminal TypeDisconnect
Overall Length (Imperial)0.87
Fastener OrientationMale
Diameter (D)0.30 Inch
Overall Width (Imperial) UOMin
UL File NumberE70512
Conductor Sizes (Imperial)22 - 18 AWG
Voltage ApplicationLow Voltage
Overall Length (Metric) UOMmm
Overall Width (Imperial)0.37
Packaging100 per bottle
Terminal StyleFully Insulated
Overall Diameter (Imperial) UOMin
Product ColorRed
Maximum Conductor Size (Imperial)18 AWG
Units per Case500.0
MaterialETP Copper
Overall Width (Metric)9.398
Overall Length (Metric)22.098
Insulation MaterialNylon with Insulation Grip
Connection Width (Metric)4.75
Overall Length (Imperial) UOMin
Overall Width (Metric) UOMmm
Minimum Conductor Size (Imperial)22 AWG
Male Tab Width (W')0.187 Inch
Connection Width (Metric) UOMmm
Minimum Conductor Size (Metric).34 mm²
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Insulation ColorRed
Barrel StyleButted
Disconnect TypeMale
Connection Width (Imperial)0.187
