3M™ Scotchlok™ Pin Nylon Insulated, 100/bottle, MNG14-47PX-A, 500/Case - 7000133348

Sold As: 100-Pack
SKU: 7000133348
MPN: 7000133348
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128587751
3M ID: 80611464217
5 Digit UPC: 58775
$123.62 ($1.24 / Count)
Hurry up! Current stock:

Product Description

3M™ Pin Terminal ensures an ideal fit while offering reliable and safe performance. The terminal has a nylon-insulated, butted-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Nylon-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Provides quick connection for set screws or clamps that are used to make electrical contact
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Funnel-designed, seamless brass sleeve offers easy insertion of wires
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance

Specifications

Country of OriginTaiwan
Maximum Insulation Outer Diameter (Imperial) UOMin
Maximum Recommended Voltage Rating UOMV
Maximum Conductor Size (Imperial)14 AWG
Maximum Operating Temperature (Celsius)105.0
Ring TypeStandard
Minimum Conductor Size (Metric)1.5 mm²
UL File NumberE23438
Maximum Operating Temperature (Fahrenheit) UOMDegree
Insulation MaterialNylon
MaterialPlastic
Maximum Insulation Outer Diameter (Metric) UOMmm
Maximum Insulation Outer Diameter (Metric)3.7
Connection Width (Imperial)0.075
Overall Length (Metric) UOMmm
Maximum Insulation Outside Diameter0.145 in
Connection Width (Metric) UOMmm
Maximum Recommended Voltage Rating600.0
Maximum Conductor Size (Metric)2.5 mm²
Terminal TypePin
Insulation ColorBlue
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Fahrenheit)221.0
Packaging100 per bottle
Connection Width (Imperial) UOMin
Pin Length (PL)0.47 Inch
Product ColorBlue
Maximum Insulation Outer Diameter (Imperial)0.2
Minimum Conductor Size (Imperial)16 AWG
Maximum Voltage Rating600 to 1000 V
Maximum Operating Temperature (Celsius) UOMDegree
Connection Width (Metric)1.905
Operating Temperature Range (Celsius)-40 °C to 105 °C
Overall Length (Metric)22.86
Overall Length (Imperial)0.9
Overall Length (Imperial) UOMin
Barrel StyleInsulation Grip
Conductor Sizes (Imperial)16 - 14 AWG
Operating Temperature Range (Fahrenheit)-40 °F to 221 °F
