3M™ Scotchlok™ Ring Non-Insulated, 50/bottle, MU10-6RX, standard-style ring tongue fits around the stud, 500/Case - 7100165275

Sold As: 500-Pack
SKU: 7100165275
MPN: 7100165275
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 10051128588571
3M ID: 80611465032
5 Digit UPC: 58857
$824.07 ($1.65 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Non-Insulated Butted Seam Ring Tongue terminal ensures an ideal fit while offering reliable and safe performance. The non-insulated, butted-seam barrel has a beveled mouth that guides the wire into position. Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • 600V-rated for building wire and 1000V for signs, fixtures or luminaires
  • Withstands a maximum temperature of 347 degrees F (175 degrees C) for bare terminals
  • Standard-style ring tongue fits around the stud
  • Non-insulated, butted-seam barrel ensures a secure fit and offers reliable performance
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Beveled mouth offers easy insertion of wires

Downloads

Specifications

Country of OriginUnited States
Maximum Conductor Size (Imperial)10 AWG
Connection Width (Metric)3.5
Barrel StyleButted
Overall Length (Imperial) UOMin
Connection Width (Imperial) UOMin
Barrel Length (Imperial)0.25 Inch
Connection Width (Metric) UOMmm
Overall Length (Imperial)0.73
Insulation MaterialNon-insulated
Terminal TypeRing
UL File NumberE23438
Overall Width (Imperial)0.38
Connection Width (Imperial)0.138
Solution forWireless Network: Infrastructure Accessories
Overall Width (Imperial) UOMin
Terminal StyleStandard
Minimum Conductor Size (Metric)3.31 mm²
Maximum Operating Temperature (Celsius)105.0
Maximum Conductor Size (Metric)5.26
Minimum Conductor Size (Imperial)12 AWG
Ring TypeStandard
Maximum Operating Temperature (Celsius) UOMDegree
