3M Products & Supplies

3M™ Squeak Reduction Tape 5430, Transparent, 1 in x 18 yd, 7.4 mil, 12 Roll/Case - 7100166322

Sold As: 24-Pack
SKU: 7100166322
MPN: 7100166322
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138964047
3M ID: 70006397650
5 Digit UPC: 96404
$2,815.61 ($117.32 / Count)
Hurry up! Current stock:

Product Description

3M™ Squeak Reduction Tape 5430 is a transparent UHMW polyethylene film tape with an acrylic adhesive. It is commonly used to control squeaks and rattles due to vibration or wear of metal and plastic parts.

Features

  • Low coefficient of friction for applications requiring slick surface
  • Excellent adhesion to many painted metal and plastic surfaces
  • High-tack acrylic adhesive provides strong initial bond for fast results and less down time
  • UHMW polyethylene backing reduces and helps eliminate noise and vibration
  • Liner ideal for fabrication and die cutting into various lengths and shapes
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Backing (Carrier) MaterialPolyethylene
Backing (Carrier) Thickness (Imperial) UOMmil
Tensile Strength (Metric) UOMN/100mm
Backing (Carrier) Thickness (Imperial)5.1
Maximum Operating Temperature (Celsius) UOMDegree
Overall Length (Metric)16.45
Total Tape Thickness without Liner (Imperial)7.4
Overall Length (Imperial)18.0
Overall Width (Metric) UOMmm
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius)107.0
Total Tape Thickness without Liner (Metric)0.19
Backing (Carrier) Thickness (Metric)0.13
Elongation at Break420%
Overall Width (Metric)25.4
IndustriesAerospace, Appliance, Automotive, Electronics, General Industrial, Metalworking, Military and Government, Specialty Vehicles, Transportation
Backing (Carrier) Thickness (Metric) UOMmm
Adhesion Strength75.0
Total Tape Thickness without Liner (Metric) UOMmm
Adhesion Strength (Metric)82.0
Product ColorTransparent
Overall Length (Metric) UOMm
Units per Case UOMRoll
Adhesion Strength (Metric) UOMN/100mm
Minimum Operating Temperature (Fahrenheit) UOMDegree
Tensile Strength (Imperial)40.0
Tensile Strength (Metric)74.5
Adhesive TypeAcrylic
Minimum Operating Temperature (Fahrenheit)-30.0
Maximum Operating Temperature (Fahrenheit)225.0
Overall Width (Imperial)1.0
Overall Length (Imperial) UOMyd
Tensile Strength (Imperial) UOMlb/in
Maximum Operating Temperature (Fahrenheit) UOMDegree
Units per Case12.0
