3M Products & Supplies

3M™ UHMW Film Tape 5421, Transparent, 2 in x 18 yd, 6.7 mil, 6 Roll/Case - 7000050076

Sold As: 6-Pack
SKU: 7000050076
MPN: 7000050076
For an accurate lead time please contact us
UPC: 00021200080098
3M ID: 70016040332
5 Digit UPC: 8009
$1,127.50 ($187.92 / Count)
Hurry up! Current stock:

Product Description

Used to protect surfaces from abrasion, 3M™ UHMW-PE Film Tape 5421 is a thin caliper general purpose polyethylene tape that creates a "slip plane" effect to allow contact without wear. This tape features a unique combination of properties that make it ideal for many tough impact wear or sliding applications. 3M™ UHMW-PE Film Tape 5421 is a thinner version of 3M™ UHMW-PE Film Tape 5423.

Features

  • Rubber adhesive provides good initial tack for immediate bonding to material surface
  • Used in applications where lubrication is not possible because of contamination
  • Can help reduce squeaks, rattles and other noises that occur with movement
  • Liner makes it ideal for fabricating or die-cutting into various lengths and shapes
  • Low coefficient of friction for “slip plane” effect between surfaces
  • Translucent, abrasion resistant backing helps protect surfaces from wear
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Overall Length (Metric)16.5
Backing (Carrier) Thickness (Imperial) UOMmil
Maximum Operating Temperature (Celsius)107.0
Overall Length (Imperial)18.0
ApplicationGeneral Industrial
Adhesion Strength (Metric)28.0
Maximum Operating Temperature (Fahrenheit)225.0
Elongation at Break440%
IndustriesAerospace, Appliance, Automotive, Electronics, General Industrial, Metalworking, Military and Government, Specialty Vehicles, Transportation
Tensile Strength (Imperial)30.0
Tensile Strength (Metric)796.0
Backing (Carrier) Thickness (Metric) UOMmm
Units per Case6.0
Primary Liner60# Densified Kraft, Silicone Treated Paper
Adhesion Strength26.0
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Imperial) UOMin
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Metric)51.0
Total Tape Thickness without Liner (Metric)0.17
Specifications MetASTM D3330, ASTM D3652, ASTM D3759
Adhesion Strength (Metric) UOMN/100mm
Adhesive TypeRubber
Product ColorTransparent
Overall Length (Metric) UOMm
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Imperial)2.0
Backing (Carrier) Thickness (Imperial)5.0
Minimum Operating Temperature (Fahrenheit)-30.0
Tensile Strength (Imperial) UOMlb/in
Total Tape Thickness without Liner (Metric) UOMmm
Backing (Carrier) Thickness (Metric)0.13
Backing (Carrier) MaterialPolyethylene
Minimum Operating Temperature (Celsius) UOMDegree
Tensile Strength (Metric) UOMN/100mm
Minimum Operating Temperature (Celsius)-34.0
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Imperial)6.7
