3M Products & Supplies

3M™ UHMW Film Tape 5423, Transparent, 5/8 in x 18 yd, 12 mil, 12 Roll/Case - 7000050079

Sold As: 12-Pack
SKU: 7000050079
MPN: 7000050079
For an accurate lead time please contact us
UPC: 00021200174971
3M ID: 70016040399
5 Digit UPC: 17497
$976.69 ($81.39 / Count)
Hurry up! Current stock:

Product Description

3M™ UHMW-PE Film Tape 5423 is a thick, general-purpose polyethylene tape made for high-impact, abrasion, and sliding applications. Its UPMW-PE (ultra-high molecular weight polyethylene) thermoplastic backing enables its low-friction and resistance to chemicals, abrasion, and vibration in demanding situations. The exceptional hardness and slick surface is ideal for maintaining a gliding, 'slip-plane' effect and reducing noises like squeaks and rattles. Furthering its workability, 3M™ UHMW-PE Film Tape 5423 is mounted on a liner, allowing the user to die-cut shapes to exact specifications. Between its low-friction coefficient, built-in liner, and long-lasting protection, this slick-surfaced tape excels in the aerospace, automotive, printing, and MRO industries.

Features

  • VERY LOW-FRICTION: Low coefficient of friction creates a 'slip plane' effect between surfaces
  • MAKE DIFFICULT SURFACES SLIPPERY: Great in applications where lubrication is not possible because of contamination
  • POWERFUL ADHESIVE: Rubber adhesive creates instant adhesion on countless surfaces
  • INSTANTLY PROTECT SURFACES: Translucent, abrasion resistant backing protects surfaces from wear
  • REDUCE UNWANTED NOISE: Can help reduce buzz, squeaks, rattles, and other noises that occur with movement
  • BUILT-IN LINER: The peel-off liner makes it ideal for fabricating or die-cutting into various part-specific lengths, shapes, and sizes
Spec Sheet



Downloads

Specifications

Country of OriginUnited States
Overall Width (Metric)16.0
Adhesive TypeRubber
Minimum Operating Temperature (Fahrenheit)-30.0
IndustriesAerospace, Appliance, Automotive, Electronics, General Industrial, MRO, Metalworking, Military and Government, Specialty Vehicles, Transportation
Total Tape Thickness without Liner (Imperial)12.0
Maximum Operating Temperature (Celsius)107.0
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Celsius)-34.0
Overall Length (Imperial)18.0
Overall Width (Metric) UOMmm
Overall Width (Imperial)0.6
Backing (Carrier) Thickness (Metric)0.25
Primary Liner60# Densified Kraft, Silicone Treated Paper
Maximum Operating Temperature (Fahrenheit)225.0
Adhesion Strength (Metric) UOMN/100mm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Elongation at Break520%
ApplicationReducing Wear Mechanical Equipment
Adhesion Strength (Metric)28.0
Total Tape Thickness without Liner (Metric)0.3
Backing (Carrier) Thickness (Metric) UOMmm
Product ColorTransparent
Minimum Operating Temperature (Celsius) UOMDegree
Tensile Strength (Metric) UOMN/cm
Backing (Carrier) Thickness (Imperial)10.0
Total Tape Thickness without Liner (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit) UOMDegree
Backing (Carrier) Thickness (Imperial) UOMmil
Overall Length (Imperial) UOMyd
Overall Length (Metric)16.5
Total Tape Thickness without Liner (Metric) UOMmm
Units per Case12.0
Backing (Carrier) MaterialPolyethylene
Overall Length (Metric) UOMm
Tensile Strength (Metric)150.0
Overall Width (Imperial) UOMin
Adhesion Strength26.0
