3M Products & Supplies

3M™ Ventureclad™ Enhanced Metal Jacketing 1577, CWE-EMJ, 35.5 in X 50 yd, 1 Roll/Case - 7100311499

SKU: 7100311499
MPN: 7100311499
For an accurate lead time please contact us
UPC: 00068060005342
3M ID: 70011144329
$1,147.47 each
Hurry up! Current stock:

Product Description

3M™ VentureClad™ Enhanced Metal Jacketing 1577CWE-EMJ is an all-weather option for various jacketing applications. It offers high resistance to weathering, mold, UV and extreme environmental conditions. This multi-layered laminate tape is designed to provide zero permeability and act as a vapor barrier The additional clear coat layer of protection makes it more resistant and durable. Zero-permeable jacketing for insulated HVAC ductwork and pipes to protect against moisture, mold, ultraviolet (UV), and extreme environmental conditions. Backed by a 10-year 3M warranty when applied per 3M installation guidelines. It comes in silver embossed.

Features

  • Available in an embossed finish with a wide range of widths and lengths
  • Designed to protect insulation materials, including fiberglass, polystyrene, mineral wool, elastomeric, phenolic foam, cellular glass, calcium silicate and conformable aerogel
  • Quick and simple install with no specialized tools.
  • Highly resistant to punctures and tears.
  • Protects against intrusion by vapor and chemical atmospheres as well as water, fungi, corrosion, oil and grease
  • Bonds and seals in cold, hot and humid conditions as low as -10°F (-23°C) with service range of -40°F (-40°C) to248°F (120°C)
Spec Sheet



Downloads

Specifications

Shelf Life730
Overall Length (Imperial)50.0
Overall Length (Metric) UOMm
IndustriesCommercial, Construction, Food and Beverage, General Industrial, Industrial, MRO, Manufacturing, Marine, Military, Military and Government
Shelf Life UOMMonth
Product ColorSilver
Adhesive TypeAcrylic
Backing MaterialMulti-layered Laminate
Primary LinerPolycoated Natural Kraft Paper
Overall Width (Metric)901.7
Overall Width (Imperial)35.5
Overall Length (Imperial) UOMyd
Overall Width (Metric) UOMmm
Overall Length (Metric)45.72
Overall Width (Imperial) UOMin
Country of OriginUnited States
Back Side Adhesive Thickness (Imperial)0.0
Backing (Carrier) Thickness (Imperial)6.0
Tensile Strength (Imperial) UOMlb/in
Maximum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Imperial)9.0
Maximum Operating Temperature (Fahrenheit)248.0
Tensile Strength (Imperial)100.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Tensile Strength (Metric) UOMN/25mm
Total Tape Thickness without Liner (Metric) UOMmm
Total Tape Thickness without Liner (Metric)0.2286
Back Side Adhesive Thickness (Metric)0.0
Minimum Operating Temperature (Celsius) UOMDegree
Backing (Carrier) Thickness (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit)-40.0
Specifications MetASTM E84 (0/5 Flame/Smoke Rating), UL 723
Maximum Operating Temperature (Celsius) UOMDegree
Tensile Strength (Metric)27.0
Total Tape Thickness without Liner (Imperial) UOMmil
Minimum Operating Temperature (Celsius)-40.0
Backing (Carrier) Thickness (Metric)0.15
Maximum Operating Temperature (Celsius)120.0
Backing (Carrier) Thickness (Metric) UOMmm
ApplicationDuctwork; Exterior Seams & Joints; HVAC Maintenance; Insulation; Sealing HVAC & Duct Work
