3M Products & Supplies

3M™ Wraparound Heat Shrink Cable Repair Sleeve HDCW-80/25-500, Length 19.7 in (500 mm), 5/case - 7100025320

Sold As: 5-Pack
SKU: 7100025320
MPN: 7100025320
Stock Item: Stock items typically ship within 2-3 business days
UPC: 04001895590658
3M ID: DE999965424
5 Digit UPC: 59065
$492.64 ($98.53 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Cable Repair Sleeve HDCW is designed to repair quickly damaged cable jacketing. This wraparound sleeve can be used as insulation material on cable and splices up to 1000V and as jacket repair material on cable up to 35 kV. The cross linked polyolefin construction has an adhesive that offers moisture seal protection.

Features

  • Rated for 35 kV applications
  • Made of adhesive-lined, cross-linked polyolefin
  • ANSI Certified and RoHS 2011/65/EU Compliant
  • Offers excellent corrosion protection on undamaged cables
  • Excellent protection against mechanical stress
  • Thick-walled sheet is tough and reliable

Downloads

Specifications

Shelf Life3600
Country of OriginGermany
Product TechnologyHeat Shrink
Inner Diameter Before Shrink (Metric) UOMmm
Jacket Repair Range0.98 to 3.15 Inch
Flame RetardantNo
Inner Diameter After Shrink (Imperial) UOMin
Overall Length (Metric) UOMmm
Product TypeSplice
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Splice TypeHeat Shrink
Inner Diameter Before Shrink (Imperial)3.94
Minimum Expanded Tubing I. D. UOMin
Minimum Shrink Temperature (Celsius)125.0
Dielectric Strength (V/mil)21 kV/mm
Inner Diameter Before Shrink (Metric)100.0
Halogen FreeYes
Elongation UOM%
Chemical ResistantYes
Inner Diameter After Shrink (Metric)23.0
Adhesive LinedYes
Cable TypeAny type of cable
Inner Diameter After Shrink (Metric) UOMmm
Voltage1 kV
Splice ConfigurationHeat Shrink Cable Repair Wrap Sleeve (HDCW)
Overall Length (Imperial)19.7
Product FormSleeve-roll
MaterialAdhesive-lined, Cross-Linked Polyolefin
Maximum Voltage Rating1 kV to 35 kV
Sleeve Length UOMin
UV ResistantYes
Overall Length (Metric)500.0
Units per Case5.0
Inner Diameter Before Shrink (Imperial) UOMin
Minimum Expanded Tubing I. D.3.66
Inner Diameter After Shrink (Imperial)0.9
Product ColorBlack
Sleeve Length19.7
Heat Shrink TypeHeat Shrink Molded Shapes
Overall Length (Imperial) UOMin
