Mag Drill unit up to 2 [50] in[mm]|JCM 200 U - 72704461120

Name: Mag Drill unit up to 2 [50] in[mm]|JCM 200 U - 72704461120
Brand: Fein Power Tools
SKU: 72704461120
Price: 2638.29 USD
Availability: InStock

SKU: 72704461120

MPN: 72704461120

Stock Item: Stock items typically ship within 2-3 business days

UPC: 4014586873060

$2,638.29

Hurry up! Current stock:

Quantity:

Product Description

Mag Drill unit up to 2 [50] in[mm]|JCM 200 U|Universal with 2-speed gearbox and outstanding functionality for flexible operation in the workshop and on the construction site.

Features

Electronic speed control.
High-power motor with stable speed.
Compact with high functionality for universal use on the construction site and in the workshop.
Reversible
Double drill motor guides enable use of the longest annular cutters.
Simple and error-proof control concept in the operator's field of view.
High magnetic holding force.

Specifications

Tool mount	MT 3
Power consumption	1,200 W
Load speed	260 - 520 rpm
Cutter max. drilling depth (mm)	50
Stroke (mm)	145
Stroke (in)	5-11/16
Weight (lbs)	30.64
Cable with plug (ft)	13.1
Cutter max. drilling depth (in)	2
HSS cutter max. dia. (mm)	40
Magnetic holding force (lbs)	2810
Max. countersinking dia. (in)	2
Cutter holder	3/4 in straight shank
Weight (kg)	13.90
HSS cutter max. dia. (in)	1-5/8
Reaming max. dia. (mm)	23
Reaming max. dia. (in)	7/8
Power output	610 W
Tapping	5/8 in [M 16]
Magnetic holding force (N)	12,500
Cable with plug (m)	4
Twist drill max. dia. (mm)	23
Twist drill max. dia. (in)	7/8
Cutter change	tool-free
Total stroke range (in)	12-3/8
Total stroke range (mm)	315
Carbide cutter max. dia. (mm)	50
Carbide cutter max. dia. (in)	2
Magnetic base dimensions	7-11/16 [195] x 3-9/16 [90] in[mm]
Max. countersinking dia. (mm)	50
