3M Products & Supplies

Scotch® Vinyl Electrical Tape 22, 1/2 in x 36 yd, Black, 2 rolls/carton, 48 rolls/Case - 7000057495

Sold As: 48-Pack
SKU: 7000057495
MPN: 7000057495
For an accurate lead time please contact us
UPC: 054007100263
3M ID: 80012017036
5 Digit UPC: 10026
$715.95 ($14.92 / Count)
Hurry up! Current stock:

Product Description

Scotch® Vinyl Electrical Tape 22 is a 10 mil thick, premium grade, heavy duty, vinyl electrical tape that's suitable for insulation applications requiring higher mechanical strength and abrasion resistance. The flame retardant tape is designed for low and high voltage bus applications and withstands a temperature range of 15 to 176 °F ( 10 to 80 °C).

Features

  • Withstands a temperature range of 15 to 176 °F (-10 to 80 °C)
  • UL Listed, ASTM Approved, VDE, CSA Certified and RoHS 2011/65/EU Compliant
  • The combination of the pressure-sensitive, rubber-resin adhesive and the PVC backing offers electrical and mechanical protection
  • Provides high resistance to UV rays, abrasion, moisture, alkalis, acids, corrosion and varying weather conditions
  • Made of durable PVC

Downloads

Specifications

Total Tape Thickness without Liner (Metric)0.25 mm
Product TypeVinyl Electrical Tapes
Adhesion Strength20 oz/in
Flame RetardantYes
Overall Length (Imperial)36 yd
Tape Length (Metric)32.9 m
Overall Width (Imperial)0.5 in
Tensile Strength (Metric)35 N/10mm
Insulation Resistance> 10^6 megohms
Minimum Operating Temperature (Celsius)-10 Degree Celsius
Self-extinguishingNo
Tape ColorBlack
Total Tape Thickness without Liner (Imperial)10 mil
Total Thickness0.25 mm
Color FamilyBlack
Voltage Rating600 V
Tape Width (Metric)12.7 mm
Maximum Operating Temperature (Fahrenheit)176 Degree Fahrenheit
Backing MaterialVinyl - Polyvinyl Chloride
UV ResistantYes
Maximum Operating Temperature (Celsius)80 Degree Celsius
Specifications MetUL Listed - CSA Certified
VulcanizingNo
ApplicationElectrical Maintenance
Overall Length (Metric)32.9 m
Adhesive MaterialBased adhesive rubber pressure sensitive
Breaking Strength (Imperial)20 lb/in
Product FormRoll
Adhesive TypeRubber
Chemical ResistantYes
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Adhesion to Steelen-CA: 21 oz. /in. (2.2 N/10 mm) - en-US: 21 oz. /in. (2.2 N/10 mm) - fr-CA: 21 oz. /in. (2.2 N/10 mm)
Suitable for High VoltageNo
Overall Width (Metric)12.7 mm
Product ColorBlack
Elongation at Break200 Percent
Tape GradePremium
