3M Products & Supplies

Scotch® Vinyl Electrical Tape 66R, 1 in x 36 yd, Black, 36 rolls/Case - 7010397041

Sold As: 36-Pack
SKU: 7010397041
MPN: 7010397041
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007432500
3M ID: 80610973382
5 Digit UPC: 43250
$926.44 ($25.73 / Count)
Hurry up! Current stock:

Product Description

Scotch® Tape 66R is a 10 mil thick, premium grade, conformable electrical tape. It provides electrical, mechanical and moisture protection with the combination of elastic, PVC backing and a pressure sensitive, rubber resin adhesive. This flame retardant tape is designed to provide electrical insulation for 600V bus bar applications.

Features

  • MULTI-PURPOSE: Functions as electrical and mechanical protection in electro-mechanical products
  • KEY SPECIFICATIONS: UL Component Recognized and RoHS Compliant
  • FLAME RETARDANT: Meets UL 510A standards as flame retardant
  • VERSATILE APPLICATION: For use as a dielectric insulating component for motors, coils, and transformers, or to function as electrical insulation in appliances or devices
  • EFFECTIVE ELECTRICAL PROTECTION: Meets the UL510A standard and is temperature rated to 221 °F (105 °C)
  • BUILT STRONG: Made with an elastic vinyl (PVC) film backing and noncorrosive rubber-based pressure-sensitive adhesive
Spec Sheet



Downloads

Specifications

Shelf Life1825
Country of OriginUnited States
Backing (Carrier) MaterialVinyl
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Celsius)105.0
Shelf Life UOMYear
Overall Length (Metric) UOMm
Maximum Operating Temperature (Fahrenheit)220.0
Total Tape Thickness without Liner (Metric) UOMmm
Adhesive TypeRubber
Voltage Rating600 V
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric)0.254
Maximum Operating Temperature (Celsius) UOMDegree
Overall Length (Metric)32.9
Overall Width (Imperial) UOMin
Overall Length (Imperial)36.0
Overall Width (Metric)25.0
Overall Width (Imperial)1.0
ApplicationElectrical Maintenance
Product ColorBlack
