3M Products & Supplies

3M™ Adhesive Transfer Tape 9485PC, Clear, 10 in x 60 yd, 5 Mil, 4/Case - 7010302044

Sold As: 4-Pack
SKU: 7010302044
MPN: 7010302044
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00021200842542
3M ID: 70006127768
5 Digit UPC: 84254
$2,285.98 ($571.50 / Count)
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape 9485PC is a 5 mil (127µm) solution that leverages the power of 3M™ High Performance Acrylic Adhesive 350, a high-performance acrylic adhesive designed for applications requiring high shear strength. Mounted on a tan, 58 lb polycoated kraft paper liner for moisture resistance and wrinkle minimization, this transfer tape is a solution for bonding high and low surface energy (HSE and LSE) materials. Additionally, this tape uses fiber reinforcement for its adhesive, improving roll stability, even in narrow widths. Choose the high-temperature performance of 3M™ Adhesive Transfer Tape 9485PC.

Features

  • Utilizes a fiber-reinforced adhesive for roll stability in narrow widths and resists both adhesive edge picking and liner confusion that can result from adhesive oozing
  • The 5 mil (127µm) thick version of 3M™ Adhesive Transfer Tape 9482PC
  • A 58 lb polycoated kraft paper liner helps provide moisture resistance while minimizing wrinkles
  • Offers resistance to humidity, water, solvent, and chemicals
  • Low odor to help improve working environment conditions
  • Leverages 3M™ High Performance Acrylic Adhesive 350 for high tack, initial adhesion, and shear strength
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
ApplicationBonding; Commerical Signs; Core Starting; Emblem Attachment; Flying splices for commercial printing; Gasket Assembly; Interior Gasket & Seal Attachment; Large Surface Lamination Assembly; Overlap Splice; Zero-Speed and General Splicing
Shelf Life UOMMonth
Overall Length (Metric)54.86
Overall Width (Imperial) UOMin
Total Tape Thickness without Liner (Metric)0.127
Primary Liner ColorTan
Primary Liner Thickness (Imperial)4.5
Units per Case UOMRoll
Overall Width (Imperial)10.0
Overall Width (Metric)254.0
Primary Liner Thickness (Imperial) UOMmil
Overall Length (Imperial)60.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Secondary Liner58# Polycoated Kraft Paper
Indoor/OutdoorIndoor/Outdoor
Units per Case4.0
Specifications MetCSA-C22.2 No. 0.15, UL 746C, UL 969
Overall Length (Metric) UOMm
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Imperial)5.0
Adhesive TypeHigh Performance Acrylic Adhesive 350
Overall Width (Metric) UOMmm
Product ColorTranslucent
Maximum Operating Temperature (Celsius)149.0
Total Tape Thickness without Liner (Metric) UOMmm
Number of Adhesive SidesDouble-sided
Primary Liner Thickness (Metric)0.11
Total Tape Thickness without Liner (Imperial) UOMmil
Primary Liner Thickness (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Fahrenheit)-40.0
IndustriesAppliance, Converter Solutions, Craft, Electronics, Furniture, General Industrial, Medical, Packaging, Paper, Point of Purchase, Print, Signage, Transportation, Woodworking
Maximum Operating Temperature (Fahrenheit)300.0
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Celsius)-40.0
Secondary Liner ColorTan
Minimum Operating Temperature (Celsius) UOMDegree
