3M Products & Supplies

3M™ Cushion-Mount™ Plus Plate Mounting Tape E1020H, White, 18 in x 25 yd, 20 mil, 1 roll per case - 7000042357

SKU: 7000042357
MPN: 7000042357
For an accurate lead time please contact us
UPC: 051125747660
3M ID: 70002019548
5 Digit UPC: 74766
$630.56 each
Hurry up! Current stock:

Product Description

Our 3M™ Cushion-Mount™ Plus Plate Mounting Tape E1020H with easy mount adhesive is designed for mounting flexographic print plates to cylinders or sleeves. This white foam mounting tape provides high quality standard combination print.

Features

  • Grooves in the adhesive are created by a cross-hatch pattern from the release liner
  • Flexographic printing, flexographic printers
  • Tape also removes cleanly from the sleeve or steel print cylinder
  • Has a standard medium density foam that is ideal for printing combinations of solids and process with halftone dots. The white foam color indicates the standard, medium density foam
  • Securely bonds the flexographic photopolymer plate to the print sleeve or steel cylinder to prevent plate edge lifting during printing
  • Has higher plate side adhesion for challenging print conditions that use thick plates or small print sleeves
  • 0.020 inch (0.51 mm) double coated foam tape has the air release feature with a plate side adhesive technology designed to resist edge lifting on flexographic print plates
  • Print plates mounted on E1020H will have no air bubbles under the plate due to the air release feature designed into the tape
  • Plate demounts from the double coated cushioned tape without adhesive residue
  • Cushioned flexographic plate mounting sticky back foam tape

Downloads

Specifications

Air ReleaseYes
Total Tape Thickness without Liner (Metric)0.56 mm
Overall Thickness (Imperial)22 mil
Product ColorWhite
Primary LinerPolycoated Polyester
Print Quality (Series)10 Series
Product FormRoll
Backing Thickness (Metric)0.559 mm
Color FamilyWhite
Print QualityCombination Printing - Standard
Adhesive TypeDifferential Acrylate
Primary Liner Thickness (Imperial)4.5 none
Application Thickness (Metric)0.5 mm
Overall Width (Metric)457 mm
Product NumberE1020H
Warranty Period2 Years from Date of Manufacture
Overall Width (Imperial)18 in
Total Tape Thickness without Liner (Imperial)22 mil
ApplicationFlexographic Plate Mounting
Composite SleevesYes
Primary Liner Thickness (Metric)0.11 mm
Backing MaterialPolyethylene Foam
Overall Length (Metric)23 m
Urethane SleevesYes
Overall Length (Imperial)25 yd
Application Thickness (Imperial)20 mil
