3M Products & Supplies

3M™ Double Coated Tape 9731, Clear, 3 in x 36 yd, 5.5 mil, 12 Roll/Case - 7000049100

Sold As: 36-Pack
SKU: 7000049100
MPN: 7000049100
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051138954086
3M ID: 70006388253
5 Digit UPC: 95408
$16,097.31 ($447.15 / Count)
Hurry up! Current stock:

Product Description

3M™ Double Coated Tape 9731 was developed with a high-performance acrylic adhesive on the face side and a silicone adhesive on the liner side of a 1 mil clear PET carrier. It is excellent for demanding applications where silicone materials must be bonded to a range of substrates.

Features

  • Ideal for attaching silicone rubber elastomers and foam
  • Features acrylic and silicone adhesives for specialized applications such as silicone gasketing
  • Double linered – Adhesive 350 on 58# 4.2 mil PCK liner and silicone adhesive on 3 mil PET liner
  • 3M™ Adhesive 350 on the face side provides exceptional temperature and chemical resistance
  • 3 mil silicone adhesive on liner side bonds well to silicone substrates
Spec Sheet



Downloads

Specifications

Shelf Life547
Country of OriginUnited States
Core Size (Metric)76.2
Carrier Thickness0.0951388888888889
Carrier MaterialPolyester Film
Back Side Adhesive Thickness (Imperial) UOMmil
Secondary Liner Thickness (Metric)0.07
Shelf Life in Months (From Date of Manufacture) UOMMonths
IndustriesAerospace, Appliance, Automotive, Converter Solutions, Electronics, General Industrial, Medical, Metalworking, Military and Government, Oil & Gas, Signage, Specialty Vehicles, Transportation
Backing (Carrier) MaterialPolyester Film
Back Side Adhesive TypeSilicone
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Width (Metric) UOMmm
Overall Width (Metric)76.2
Core Size (Metric) UOMmm
Overall Thickness (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit) UOMDegree
Carrier Thickness UOMmil
Back Side Adhesive Thickness (Imperial)2.9
Core Size (Imperial) UOMin
Overall Length (Metric) UOMm
Minimum Operating Temperature (Celsius) UOMDegree
Secondary Liner Thickness (Imperial)2.9
Overall Length (Imperial)36.0
Secondary Liner Thickness (Imperial) UOMmil
Shelf Life UOMMonth
Maximum Operating Temperature (Fahrenheit)250.0
Carrier Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Imperial) UOMmil
Master Size Length (Metric) UOMm
Face Side Adhesive TypeHigh Performance Acrylic Adhesive 350
Master Size Width (Metric)122.0
Maximum Operating Temperature (Celsius)121.0
Primary Liner ColorTan
Face Side Adhesive Thickness (Imperial) UOMmil
Adhesive TypeAcrylic/Silicone
Indoor/OutdoorBoth
Core Size (Imperial)3.0
Carrier Thickness (Metric)0.03
Primary Liner Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Metric) UOMmm
Overall Thickness (Imperial)5.5
Overall Length (Metric)33.0
Units per Case12.0
Face Side Adhesive Thickness (Metric)0.041
Primary Liner58# Polycoated Kraft Paper (PCK)
Back Side Adhesive Thickness (Metric) UOMmm
Backing (Carrier) Thickness (Imperial)1.0
Master Size Length (Metric)98.8
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric)0.14
Master Size Width (Metric) UOMcm
Secondary Liner Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Imperial)5.5
Assembly TypeGasket Attachment
Shelf Life in Months (From Date of Manufacture)12.0
Backing (Carrier) Thickness (Metric)0.025
Tape TypeDouble Coated
Primary Liner Thickness (Imperial)4.2
Overall Width (Imperial) UOMin
Minimum Operating Temperature (Fahrenheit)-40.0
Minimum Operating Temperature (Celsius)-40.0
Product ColorTransparent
Total Tape Thickness without Liner (Imperial) UOMmil
Face Side Adhesive Thickness (Metric) UOMmm
Primary Liner Thickness (Imperial) UOMmil
Face Side Adhesive Thickness (Imperial)1.6
Product FormRoll
Overall Width (Imperial)3.0
Total Tape Thickness without Liner (Metric) UOMmm
Primary Liner Thickness (Metric)0.17
