3M Products & Supplies

3M™ EMI Absorber AB6005HF, 25 mm x 10 m Roll - 7010321488

Sold As: 5-Pack
SKU: 7010321488
MPN: 7010321488
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 18806080063770
3M ID: WX300926986
5 Digit UPC: 6377
$744.68 ($148.94 / Count)
Hurry up! Current stock:

Product Description

3M™ EMI Shielding Absorber AB6000HF/SHF Series is a hybrid shielding magnetic absorber consisting of a metal EMI shielding layer and absorbing layer with an insulation layer in between. The 3M AB6000HF/SHF provides good EMI absorbing and high-frequency EMI shielding for a lower signal-to-noise ratio (SNR). An acrylic pressure-sensitive adhesive and a removable release liner make applying the material easy and efficient. Available in sheets and rolls, these EMI absorbers are excellent for complex EMI applications requiring noise suppression, and shielding up to 18 GHz.

Features

  • Acrylic non-conductive pressure sensitive adhesive makes for fast, simple application
  • PET absorber reduces EMI and ESD in enclosed cavities
  • Removable liner makes material easy to handle
  • Aluminum layer provides excellent shielding effectiveness up to 18 GHz
  • Broad temperature performance -30C - 105C
  • Excellent for EMI shielding and insulation in a range of applications
Spec Sheet



Downloads

Specifications

Country of OriginSouth Korea
Overall Width (Metric) UOMmm
Overall Length (Imperial)10.936
Overall Thickness (Imperial)5.905
Frequency Range10 MHz - 18 GHz
Number of Adhesive Sides1
AdhesivePressure-sensitive Acrylic
ApplicationEMI Shielding
Total Tape Thickness without Liner (Imperial)0.0
Total Thickness0.105 mm
Overall Thickness (Metric)0.15
Overall Thickness (Metric) UOMmm
Product UsageCables; Camera Modules; Display Chip on Flex; EMI Shields; Flexible Printed Circuits; Printed Circuit Boards; Sensors
Overall Width (Imperial) UOMin
Overall Length (Imperial) UOMyd
Total Thickness (Metric)0.105
Overall Width (Metric)25.0
Adhesive Thickness (Imperial)0.0
Adhesive Thickness (Metric)0.0
Overall Width (Imperial)0.984
Overall Length (Metric)10.0
Overall Thickness (Imperial) UOMmil
Overall Length (Metric) UOMm
