3M Products & Supplies

3M™ Scotchlok™ Male Disconnect Heatshrink Nylon Insulated, 25/bottle, MNHU10-250DMIX, 125/Case - 7000133383

Sold As: 25-Pack
SKU: 7000133383
MPN: 7000133383
For an accurate lead time please contact us
UPC: 00051128588963
3M ID: 80611465420
5 Digit UPC: 58896
$64.24 ($2.57 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Color-Coded Heat Shrink Male Disconnect Terminal allows for quick and easy disconnect. The butted-seam barrel is covered by an adhesive-lined polyolefin tubing to offer moisture-seal protection. It withstands a maximum temperature of 221 degrees F (105 degrees C). Its electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Withstands a maximum temperature of 221 degrees F (105 degrees C)
  • Rated 600V for building wire and 1000V for signs, fixtures or luminaires
  • When crimped and shrunk, pre-insulated adhesive-lined polyolefin offers seal resistance to water and salt
  • Mates with 0.25-in wide female tab
  • This male disconnect terminal offers excellent holding force
  • Made of electrolytic copper for good conductivity and has corrosion-resistant tin plating

Downloads

Specifications

Country of OriginUnited States
Insulation MaterialHeat Shrink
Overall Width (Imperial) UOMin
Overall Width (Imperial)0.47
Product ColorYellow
Maximum Conductor Size (Imperial)10 AWG
Diameter (D)0.39 Inch
Fastener OrientationMale
Connection Width (Metric) UOMmm
Overall Length (Metric) UOMmm
Maximum Operating Temperature (Celsius) UOMDegree
Maximum Operating Temperature (Fahrenheit)221.0
Conductor Sizes (Imperial)12 - 10 AWG
Overall Length (Imperial)1.2
Maximum Insulation Outer Diameter (Imperial)0.145
Connection Width (Imperial) UOMin
Connection Width (Metric)6.35
Maximum Insulation Outer Diameter (Imperial) UOMin
Overall Diameter (Imperial) UOMin
Maximum Recommended Voltage Rating UOMV
Terminal TypeDisconnect
Overall Diameter (Imperial)0.39
Units per Case125.0
Minimum Conductor Size (Metric)4 mm²
Barrel Inside Diameter0.150 Inch
Terminal StyleFully Insulated
Minimum Conductor Size (Imperial)12 AWG
Maximum Recommended Voltage Rating600.0
Voltage ApplicationLow Voltage
Insulation ColorYellow
Connection Width (Imperial)0.25
MaterialPlastic
Overall Width (Metric) UOMmm
Male Tab Width (W')0.250 Inch
Disconnect TypeMale
Maximum Operating Temperature (Celsius)105.0
Overall Length (Imperial) UOMin
Tab Width0.110
Overall Width (Metric)11.93
Maximum Conductor Size (Metric)6 mm²
Pad Width0.25
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric)30.48
Packaging25 per bottle
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Insulation Outer Diameter (Metric)3.7
Maximum Insulation Outer Diameter (Metric) UOMmm
Barrel StyleButted
