3M Products & Supplies

3M™ Scotchlok™ Ring Tongue MN24-8RK, standard-style ring tongue fits around the stud, 1000/Case - 7100165003

Sold As: 1000-Pack
SKU: 7100165003
MPN: 7100165003
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00054007951612
3M ID: 80611256613
5 Digit UPC: 95161
$1,273.56 ($1.27 / Count)
Hurry up! Current stock:

Product Description

3M™ Scotchlok™ Ring Tongue Terminal ensures an ideal fit while offering reliable and safe performance. The terminal has a nylon-insulated, brazed-seam barrel and withstands temperatures of -40 to 221 degrees F (-40 to 105 degrees C). Electrolytic copper construction offers good conductivity and a tin-plated finish resists corrosion.

Features

  • Flared portion of the nylon sleeve offers easy insertion of wires
  • Nylon-insulated, brazed-seam barrel ensures a secure fit and offers reliable performance
  • Withstands a temperature range of -40 to 221 degrees F (-40 to 105 degrees C)
  • Made of electrolytic copper for good conductivity and has tin plating for corrosion resistance
  • Standard-style ring tongue fits around the stud

Downloads

Specifications

Country of OriginTaiwan
Connection Width (Imperial) UOMin
Barrel Length (Imperial)0.39 Inch
Maximum Conductor Size (Imperial)24 AWG
Maximum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Imperial) UOMin
Terminal TypeRing
Ring TypeStandard
Terminal StyleStandard
Minimum Conductor Size (Metric).14 mm²
Maximum Operating Temperature (Celsius)105.0
Operating Temperature Range (Celsius)-40 °C to 105 °C
Minimum Conductor Size (Imperial)26 AWG
Connection TypeCrimp
UL File NumberE23438
Barrel StyleBrazed Seam
Connection Width (Imperial)0.164
Connection Width (Metric)4.166
Maximum Recommended Voltage Rating600.0
Maximum Recommended Voltage Rating UOMV
Insulation MaterialNylon
Maximum Operating Temperature (Fahrenheit)221.0
Operating Temperature (Fahrenheit)-40 °F to 221 °F
Maximum Voltage Rating600 to 1000 V
Overall Width (Imperial)0.25
Operating Temperature Range (Fahrenheit)-40 °F to 221 °F
Overall Width (Imperial) UOMin
Overall Length (Imperial)0.69
Maximum Conductor Size (Metric)0.205
Maximum Operating Temperature (Celsius) UOMDegree
Connection Width (Metric) UOMmm
