3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 3-1/2 in x 36 yd, 3 in Paper Core, 2 Rolls/Case - 7100168547

Sold As: 2-Pack
SKU: 7100168547
MPN: 7100168547
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128618370
3M ID: 80611626864
5 Digit UPC: 61837
$1,530.80 ($765.40 / Count)
Hurry up! Current stock:

Product Description

3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Unique adhesive creates secure contact with the application surface
  • Comes on a removable liner for easy die-cutting and handling
  • Rated for 600V applications
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Suitable for grounding and EMI shielding equipment, components and shielded rooms
  • Flame-retardant

Downloads

Specifications

Shelf Life1825
Country of OriginTaiwan
Overall Width (Metric)82.55
Product MarketsElectrical Equipment Manufacturing
Total Tape Thickness without Liner (Metric)0.066
Backing (Carrier) MaterialTin Plated Copper Foil, Flat
Tensile Strength (Metric)44.0
Product ColorTin
Total Tape Thickness without Liner (Metric) UOMmm
MaterialTin Plated Copper Foil
Overall Width (Metric) UOMmm
Overall Width (Imperial)3.25
Shelf Life UOMYear
Adhesive TypeConductive Acrylic
Tape GradeProfessional
ApplicationShielding
Specifications MetRoHS 2011/65/EU, UL Listed, UL Recognized
Tensile Strength (Metric) UOMN/cm
Overall Width (Imperial) UOMin
