3M Products & Supplies

3M™ Tin-Plated Copper Foil EMI Shielding Tape 1183, 41 mm x 50 m, 3 in Paper Core, 7 Rolls/Case - 7100040587

Sold As: 14-Pack
SKU: 7100040587
MPN: 7100040587
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00051128609446
3M ID: 80611612690
5 Digit UPC: 60944
$7,064.88 ($504.63 / Count)
Hurry up! Current stock:

Product Description

3M™ Tin Plated Copper Foil EMI Shielding Tape 1183 is a 2.6 mil thick, acrylic adhesive shielding tape. This flame retardant tape is suitable for applications that require outstanding electrical conductivity from the application substrate through the adhesive to the backing. It comes on a removable liner for easy die cutting and handling. The tape is rated for 600V dry applications.

Features

  • Suitable for grounding and EMI shielding equipment, components and shielded rooms
  • Flame-retardant
  • Unique adhesive creates secure contact with the application surface
  • Comes on a removable liner for easy die-cutting and handling
  • Withstands a wide temperature range of -40 to 266 °F (-40 to 130 °C)
  • Rated for 600V applications

Specifications

Shelf Life1825
Country of OriginTaiwan
Overall Length (Metric) UOMm
Overall Width (Imperial)1.6
Overall Width (Metric) UOMmm
Overall Length (Metric)55.0
Overall Width (Imperial) UOMin
Tensile Strength (Metric) UOMN/cm
Backing (Carrier) Thickness (Metric) UOMmm
Total Tape Thickness without Liner (Metric) UOMmm
Overall Width (Metric)41.0
Overall Length (Imperial) UOMyd
Overall Length (Imperial)60.0
Backing (Carrier) Thickness (Imperial) UOMmil
ApplicationShielding
Tape GradeProfessional
Total Tape Thickness without Liner (Metric)0.066
Product MarketsElectrical Equipment Manufacturing
Backing (Carrier) MaterialTin Plated Copper Foil, Flat
Tensile Strength (Metric)44.0
Adhesive TypeConductive Acrylic
Product ColorTin
Backing (Carrier) Thickness (Imperial)1.4
Backing (Carrier) Thickness (Metric)0.035
Shelf Life UOMYear
MaterialTin Plated Copper Foil
Specifications MetRoHS 2011/65/EU, UL Listed, UL Recognized
