3M Products & Supplies

3M™ Ventureclad™ Enhanced Metal Jacketing 1579, CW-EMJ, 6 in X 25 yd, 4 Rolls/Case - 7100311989

Sold As: 144-Pack
SKU: 7100311989
MPN: 7100311989
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060005359
3M ID: 70011144345
$26,068.51 ($181.03 / Count)
Hurry up! Current stock:

Product Description

3M™ VentureClad™ Enhanced Metal Jacketing 1579CW-EMJ is an all-weather option for various jacketing applications. It offers high resistance to weathering, mold, UV and extreme environmental conditions. This multi-layered laminate tape is designed to provide zero permeability and act as a vapor barrier. The additional clear coat layer of protection makes it more resistant and durable. Zero-permeable jacketing for insulated HVAC ductwork and pipes to protect against moisture, mold, ultraviolet (UV), and extreme environmental conditions. Backed by a 10-year 3M warranty when applied per 3M installation guidelines. It comes in silver smooth.

Features

  • Available in a smooth finish with a wide range of widths and lengths
  • Bonds and seals in cold, hot and humid conditions as low as -10°F (-23°C) with service range of -40°F (-40°C) to248°F (120°C)
  • Protects against intrusion by vapor and chemical atmospheres as well as water, fungi, corrosion, oil and grease
  • Designed to protect insulation materials, including fiberglass, polystyrene, mineral wool, elastomeric, phenolic foam, cellular glass, calcium silicate and conformable aerogel
  • Highly resistant to punctures and tears.
  • Quick and simple install with no specialized tools.
Spec Sheet



Downloads

Specifications

Shelf Life730
Total Tape Thickness without Liner (Metric)0.381
Overall Length (Metric) UOMm
Tensile Strength (Metric)36.0
Specifications MetASTM E84 (0/5 Flame/Smoke Rating), UL 723
Minimum Operating Temperature (Celsius)-40.0
ApplicationDuctwork; Exterior Seams & Joints; HVAC Maintenance; Insulation; Sealing HVAC & Duct Work
Overall Width (Metric) UOMmm
Minimum Operating Temperature (Fahrenheit)-40.0
Maximum Operating Temperature (Fahrenheit)248.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Backing (Carrier) Thickness (Imperial) UOMmil
Back Side Adhesive Thickness (Imperial)0.0
Maximum Operating Temperature (Celsius)120.0
Overall Length (Imperial) UOMyd
Total Tape Thickness without Liner (Metric) UOMmm
Shelf Life UOMMonth
Back Side Adhesive Thickness (Metric)0.0
Backing (Carrier) Thickness (Metric) UOMmm
Primary LinerPolycoated Natural Kraft Paper
Tensile Strength (Imperial)130.0
Backing MaterialMulti-layered, reinforced laminate
Adhesive TypeAcrylic
Overall Width (Metric)152.4
Backing (Carrier) Thickness (Imperial)13.0
Overall Length (Imperial)25.0
Tensile Strength (Metric) UOMN/25mm
Backing (Carrier) Thickness (Metric)0.33
IndustriesCommercial, Construction, Food and Beverage, General Industrial, Industrial, MRO, Manufacturing, Marine, Military, Military and Government
Tensile Strength (Imperial) UOMlb/in
Overall Length (Metric)22.86
Maximum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius) UOMDegree
Country of OriginUnited States
Total Tape Thickness without Liner (Imperial) UOMmil
Total Tape Thickness without Liner (Imperial)15.0
Product ColorSilver
Overall Width (Imperial)6.0
Overall Width (Imperial) UOMin
Maximum Operating Temperature (Celsius) UOMDegree
