3M Products & Supplies

3M™ Ventureclad™ Enhanced Metal Jacketing 1579, CW-EMJ, 6 in X 25 yd, 4 Rolls/Case - 7100311989

Sold As: 144-Pack
SKU: 7100311989
MPN: 7100311989
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060005359
3M ID: 70011144345
$26,068.51 ($181.03 / Count)
Hurry up! Current stock:

Product Description

3M™ VentureClad™ Enhanced Metal Jacketing 1579CW-EMJ is an all-weather option for various jacketing applications. It offers high resistance to weathering, mold, UV and extreme environmental conditions. This multi-layered laminate tape is designed to provide zero permeability and act as a vapor barrier. The additional clear coat layer of protection makes it more resistant and durable. Zero-permeable jacketing for insulated HVAC ductwork and pipes to protect against moisture, mold, ultraviolet (UV), and extreme environmental conditions. Backed by a 10-year 3M warranty when applied per 3M installation guidelines. It comes in silver smooth.

Features

  • Protects against intrusion by vapor and chemical atmospheres as well as water, fungi, corrosion, oil and grease
  • Bonds and seals in cold, hot and humid conditions as low as -10°F (-23°C) with service range of -40°F (-40°C) to248°F (120°C)
  • Highly resistant to punctures and tears.
  • Available in a smooth finish with a wide range of widths and lengths
  • Designed to protect insulation materials, including fiberglass, polystyrene, mineral wool, elastomeric, phenolic foam, cellular glass, calcium silicate and conformable aerogel
  • Quick and simple install with no specialized tools.
Spec Sheet



Downloads

Specifications

Shelf Life730
Overall Length (Metric) UOMm
Overall Width (Metric) UOMmm
Overall Length (Imperial) UOMyd
Shelf Life UOMMonth
Primary LinerPolycoated Natural Kraft Paper
Backing MaterialMulti-layered, reinforced laminate
Adhesive TypeAcrylic
Overall Width (Metric)152.4
Overall Length (Imperial)25.0
IndustriesCommercial, Construction, Food and Beverage, General Industrial, Industrial, MRO, Manufacturing, Marine, Military, Military and Government
Overall Length (Metric)22.86
Country of OriginUnited States
Product ColorSilver
Overall Width (Imperial)6.0
Overall Width (Imperial) UOMin
Backing (Carrier) Thickness (Metric)0.33
Backing (Carrier) Thickness (Imperial) UOMmil
Minimum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Fahrenheit)-40.0
ApplicationDuctwork; Exterior Seams & Joints; HVAC Maintenance; Insulation; Sealing HVAC & Duct Work
Back Side Adhesive Thickness (Imperial)0.0
Total Tape Thickness without Liner (Imperial)15.0
Total Tape Thickness without Liner (Metric) UOMmm
Minimum Operating Temperature (Celsius)-40.0
Total Tape Thickness without Liner (Imperial) UOMmil
Specifications MetASTM E84 (0/5 Flame/Smoke Rating), UL 723
Maximum Operating Temperature (Fahrenheit) UOMDegree
Maximum Operating Temperature (Celsius) UOMDegree
Tensile Strength (Imperial)130.0
Back Side Adhesive Thickness (Metric)0.0
Maximum Operating Temperature (Fahrenheit)248.0
Maximum Operating Temperature (Celsius)120.0
Backing (Carrier) Thickness (Metric) UOMmm
Tensile Strength (Imperial) UOMlb/in
Backing (Carrier) Thickness (Imperial)13.0
Tensile Strength (Metric) UOMN/25mm
Minimum Operating Temperature (Celsius) UOMDegree
Tensile Strength (Metric)36.0
Total Tape Thickness without Liner (Metric)0.381
