3M Products & Supplies

3M™ Ventureclad™ Enhanced Metal Jacketing 1579, CW-EMJ, 46 in X 25 yd, 1 Roll/Case - 7100312085

SKU: 7100312085
MPN: 7100312085
Made to Order: For a lead time estimate, please send your request to [email protected]
UPC: 00068060005441
3M ID: 70011144410
$1,387.97 each
Hurry up! Current stock:

Product Description

3M™ VentureClad™ Enhanced Metal Jacketing 1579CW-EMJ is an all-weather option for various jacketing applications. It offers high resistance to weathering, mold, UV and extreme environmental conditions. This multi-layered laminate tape is designed to provide zero permeability and act as a vapor barrier. The additional clear coat layer of protection makes it more resistant and durable. Zero-permeable jacketing for insulated HVAC ductwork and pipes to protect against moisture, mold, ultraviolet (UV), and extreme environmental conditions. Backed by a 10-year 3M warranty when applied per 3M installation guidelines. It comes in silver smooth.

Features

  • Available in a smooth finish with a wide range of widths and lengths
  • Designed to protect insulation materials, including fiberglass, polystyrene, mineral wool, elastomeric, phenolic foam, cellular glass, calcium silicate and conformable aerogel
  • Highly resistant to punctures and tears.
  • Protects against intrusion by vapor and chemical atmospheres as well as water, fungi, corrosion, oil and grease
  • Bonds and seals in cold, hot and humid conditions as low as -10°F (-23°C) with service range of -40°F (-40°C) to248°F (120°C)
  • Quick and simple install with no specialized tools.
Spec Sheet



Downloads

Specifications

Shelf Life730
Product ColorSilver
ApplicationDuctwork; Exterior Seams & Joints; HVAC Maintenance; Insulation; Sealing HVAC & Duct Work
Overall Length (Imperial)25.0
Primary LinerPolycoated Natural Kraft Paper
Overall Width (Imperial) UOMin
Overall Width (Imperial)46.0
Country of OriginUnited States
Overall Width (Metric) UOMmm
Backing MaterialMulti-layered, reinforced laminate
IndustriesCommercial, Construction, Food and Beverage, General Industrial, Industrial, MRO, Manufacturing, Marine, Military, Military and Government
Adhesive TypeAcrylic
Overall Width (Metric)1168.4
Overall Length (Imperial) UOMyd
Overall Length (Metric) UOMm
Overall Length (Metric)22.86
Maximum Operating Temperature (Fahrenheit) UOMDegree
Backing (Carrier) Thickness (Imperial)13.0
Total Tape Thickness without Liner (Imperial) UOMmil
Backing (Carrier) Thickness (Metric) UOMmm
Maximum Operating Temperature (Celsius) UOMDegree
Minimum Operating Temperature (Fahrenheit)-40.0
Total Tape Thickness without Liner (Metric)0.381
Tensile Strength (Metric) UOMN/25mm
Backing (Carrier) Thickness (Metric)0.33
Total Tape Thickness without Liner (Imperial)15.0
Minimum Operating Temperature (Fahrenheit) UOMDegree
Minimum Operating Temperature (Celsius)-40.0
Specifications MetASTM E84 (0/5 Flame/Smoke Rating), UL 723
Back Side Adhesive Thickness (Imperial)0.0
Maximum Operating Temperature (Celsius)120.0
Backing (Carrier) Thickness (Imperial) UOMmil
Tensile Strength (Metric)36.0
Total Tape Thickness without Liner (Metric) UOMmm
Shelf Life UOMMonth
Back Side Adhesive Thickness (Metric)0.0
Minimum Operating Temperature (Celsius) UOMDegree
Tensile Strength (Imperial) UOMlb/in
Maximum Operating Temperature (Fahrenheit)248.0
Tensile Strength (Imperial)130.0
