3M Products & Supplies

3M™ Adhesive Transfer Tape 9485PC, Clear, 1 in x 60 yd, 5 mil, 36 Roll/Case - 7000123367

Sold As: 36-Pack
SKU: 7000123367
MPN: 7000123367
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00021200634772
3M ID: 70006083623
5 Digit UPC: 63477
$2,057.39 ($57.15 / Count)
Hurry up! Current stock:

Product Description

3M™ Adhesive Transfer Tape 9485PC is a 5 mil (127µm) solution that leverages the power of 3M™ High Performance Acrylic Adhesive 350, a high-performance acrylic adhesive designed for applications requiring high shear strength. Mounted on a tan, 58 lb polycoated kraft paper liner for moisture resistance and wrinkle minimization, this transfer tape is a solution for bonding high and low surface energy (HSE and LSE) materials. Additionally, this tape uses fiber reinforcement for its adhesive, improving roll stability, even in narrow widths. Choose the high-temperature performance of 3M™ Adhesive Transfer Tape 9485PC.

Features

  • Utilizes a fiber-reinforced adhesive for roll stability in narrow widths and resists both adhesive edge picking and liner confusion that can result from adhesive oozing
  • Offers resistance to humidity, water, solvent, and chemicals
  • A 58 lb polycoated kraft paper liner helps provide moisture resistance while minimizing wrinkles
  • Leverages 3M™ High Performance Acrylic Adhesive 350 for high tack, initial adhesion, and shear strength
  • The 5 mil (127µm) thick version of 3M™ Adhesive Transfer Tape 9482PC
  • Low odor to help improve working environment conditions
Spec Sheet



Downloads

Specifications

Shelf Life730
Country of OriginUnited States
Primary Liner Thickness (Imperial) UOMmil
Shelf Life UOMMonth
Maximum Operating Temperature (Fahrenheit) UOMDegree
Total Tape Thickness without Liner (Metric)0.127
Units per Case36.0
IndustriesAppliance, Converter Solutions, Craft, Electronics, Furniture, General Industrial, Medical, Packaging, Paper, Point of Purchase, Print, Signage, Transportation, Woodworking
Total Tape Thickness without Liner (Imperial) UOMmil
Overall Width (Imperial)1.0
Units per Case UOMRoll
Overall Width (Imperial) UOMin
Indoor/OutdoorIndoor/Outdoor
Secondary Liner58# Polycoated Kraft Paper
Secondary Liner ColorTan
Adhesive TypeHigh Performance Acrylic Adhesive 350
Minimum Operating Temperature (Celsius) UOMDegree
Overall Width (Metric)25.4
Primary Liner Thickness (Metric)0.11
Total Tape Thickness without Liner (Imperial)5.0
Minimum Operating Temperature (Fahrenheit)-40.0
Primary Liner Thickness (Metric) UOMmm
Overall Width (Metric) UOMmm
Maximum Operating Temperature (Celsius) UOMDegree
Number of Adhesive SidesDouble-sided
Primary Liner ColorTan
Product ColorTranslucent
Maximum Operating Temperature (Fahrenheit)300.0
Specifications MetCSA-C22.2 No. 0.15, UL 746C, UL 969
Minimum Operating Temperature (Fahrenheit) UOMDegree
Overall Length (Metric) UOMm
Maximum Operating Temperature (Celsius)149.0
Total Tape Thickness without Liner (Metric) UOMmm
Overall Length (Metric)54.86
Primary Liner Thickness (Imperial)4.5
Minimum Operating Temperature (Celsius)-40.0
ApplicationBonding; Commerical Signs; Core Starting; Emblem Attachment; Flying splices for commercial printing; Gasket Assembly; Interior Gasket & Seal Attachment; Large Surface Lamination Assembly; Overlap Splice; Zero-Speed and General Splicing
Overall Length (Imperial)60.0
Overall Length (Imperial) UOMyd
