3M Products & Supplies

3M™ Thin-Wall Heat Shrink Tubing EPS-300, Adhesive-Lined, 1/8-48"-Black-25 Pcs, 48 in length sticks, 25 pieces/case - 7000133593

Sold As: 25-Pack
SKU: 7000133593
MPN: 7000133593
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128597705
3M ID: 80611600315
5 Digit UPC: 59770
$286.65 ($11.47 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing EPS-300 is a dual wall tubing provides the advantage of an integral, adhesive lined construction. This flame retardant tubing with a 3:1 shrink ratio offers insulation for 600V rated applications. The flexible polyolefin construction features an internal layer of thermoplastic adhesive, which offers moisture seal protection in automotive and marine applications.

Features

  • Made of black flexible polyolefin
  • Offers protection for automotive, truck, electronic components, wire splices, wire bundles and harness breakouts
  • Offers the advantage of integral, adhesive-lined construction
  • Withstands temperatures of -67 to 230 degrees F (-55 to 110 degrees C)
  • Dual-wall construction provides abrasion resistance and moisture-seal protection
  • Flame-retardant tubing is rated for 600V applications
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Minimum Expanded Tubing I. D. UOMin
Adhesive MaterialSilicone
Inner Diameter Before Shrink (Metric) UOMmm
Maximum Operating Temperature (Fahrenheit)230.0
MaterialPolyolefin
UL File NumberE-157227
Elongation UOM%
Flame RetardantYes
Operating Temperature (Celsius)-55 °C to 110 °C
Operating Temperature Range (Celsius)-55 °C to 110 °C
Operating Temperature Range (Fahrenheit)-67 °F to 230 °F
Overall Length (Imperial) UOMft
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Tubing TypeDual Wall (Adhesive Lined)
Maximum Operating Temperature (Fahrenheit) UOMDegree
Units per Case25.0
Inner Diameter After Shrink (Metric)1.02
Inner Diameter Before Shrink (Imperial) UOMin
Inner Diameter After Shrink (Metric) UOMmm
Maximum Operating Temperature (Celsius)110.0
Non-CorrosiveYes
Inner Diameter Before Shrink (Metric)3.18
Overall Length (Imperial)4.0
Product ColorBlack
Operating Temperature (Fahrenheit)-67 °F to 230 °F
Heat Shrink TypeAdhesive-Lined Polyolefin Heat Shrink Tubing
Inner Diameter Before Shrink (Imperial)0.125
Minimum Expanded Tubing I. D.0.125
Shrink Ratio3:1
Inner Diameter After Shrink (Imperial)0.04
Maximum Operating Temperature (Celsius) UomDegree
Inner Diameter After Shrink (Imperial) UOMin
