3M Products & Supplies

3M™ Thin-Wall Heat Shrink Tubing EPS-300, Adhesive-Lined, 3/4-48"-Clear-45 Pcs, 48 in length sticks, 45 pieces/case - 7010398851

Sold As: 45-Pack
SKU: 7010398851
MPN: 7010398851
Stock Item: Stock items typically ship within 2-3 business days
UPC: 00051128597590
3M ID: 80611600208
5 Digit UPC: 59759
$507.52 ($11.28 / Count)
Hurry up! Current stock:

Product Description

3M™ Heat Shrink Tubing EPS-300 is a dual wall tubing provides the advantage of an integral, adhesive lined construction. This flame retardant tubing with a 3:1 shrink ratio offers insulation for 600V rated applications. The flexible polyolefin construction features an internal layer of thermoplastic adhesive, which offers moisture seal protection in automotive and marine applications.

Features

  • Offers protection for automotive, truck, electronic components, wire splices, wire bundles and harness breakouts
  • Dual-wall construction provides abrasion resistance and moisture-seal protection
  • Made of black flexible polyolefin
  • Offers the advantage of integral, adhesive-lined construction
  • Withstands temperatures of -67 to 230 degrees F (-55 to 110 degrees C)
  • Flame-retardant tubing is rated for 600V applications
Spec Sheet



Downloads

Specifications

Shelf Life3600
Country of OriginUnited States
Shrink Ratio3:1
Inner Diameter Before Shrink (Imperial)0.75
Tubing TypeDual Wall (Adhesive Lined)
Non-CorrosiveYes
Operating Temperature (Fahrenheit)-67 °F to 230 °F
Minimum Expanded Tubing I. D.0.75
Inner Diameter Before Shrink (Metric) UOMmm
Inner Diameter Before Shrink (Imperial) UOMin
Inner Diameter After Shrink (Imperial)0.25
RoHS EU CommentsRoHS 2011/65/EU compliant without exemption
Maximum Operating Temperature (Celsius)110.0
Operating Temperature (Celsius)-55 °C to 110 °C
Maximum Operating Temperature (Fahrenheit) UOMDegree
MaterialPolyolefin
Product ColorTransparent
Heat Shrink TypeAdhesive-Lined Polyolefin Heat Shrink Tubing
Adhesive MaterialSilicone
Maximum Operating Temperature (Celsius) UomDegree
Inner Diameter Before Shrink (Metric)19.05
Inner Diameter After Shrink (Metric)6.35
Flame RetardantYes
Units per Case45.0
Inner Diameter After Shrink (Metric) UOMmm
Overall Length (Imperial)48.0
Maximum Operating Temperature (Fahrenheit)230.0
Minimum Expanded Tubing I. D. UOMin
Overall Length (Imperial) UOMin
Inner Diameter After Shrink (Imperial) UOMin
